Findeva DAR-3 is a heavy-duty pneumatic roller vibrator developed for applications requiring high centrifugal force, including concrete compaction and bulk-material flow. The model provides continuously variable vibration performance across the published 2, 4 and 6 bar operating points.
The DAR-3 uses a rotating cast-steel roller running in highly flexible steel guides. The housing is made from extruded aluminium alloy and reinforced with shock-resistant bronze covers.
At 2, 4 and 6 bar the DAR-3 operates at 27.0, 31.0 and 32.0 ×10³ min⁻¹ and generates 2720, 4560 and 6050 N centrifugal force.
Published air consumption is 100, 200 and 300 l/min at 2, 4 and 6 bar.
| Brand | Findeva |
|---|---|
| Product family | DAR Roller Vibrator |
| Model | DAR-3 |
| Rated frequency @ 2 / 4 / 6 bar | 27.0 / 31.0 / 32.0 ×10³ min⁻¹ |
| Centrifugal force @ 2 / 4 / 6 bar | 2720 / 4560 / 6050 N |
| Air consumption @ 2 / 4 / 6 bar | 100 / 200 / 300 l/min |
| Dimensions A / Width / C / D / E / F | 65 / 36 / 113 / 90 / 16 / 9 mm |
| Thread | G 1/4" |
| Weight | 0.76 kg |
| Maximum operating temperature | 150°C |
Compacting plastic and concrete, assisting material flow in silos and hoppers, and separating different-sized products on sieves.
The Roller Vibrators DAR-3 is designed for compressed-air operation within the published Findeva operating range. Its model-specific construction and pneumatic characteristics provide controlled vibration or impact for material-flow and process equipment.
| Brand | Findeva |
|---|---|
| Product family | DAR Roller Vibrator |
| Model | DAR-3 |
| Rated frequency @ 2 / 4 / 6 bar | 27.0 / 31.0 / 32.0 ×10³ min⁻¹ |
| Centrifugal force @ 2 / 4 / 6 bar | 2720 / 4560 / 6050 N |
| Air consumption @ 2 / 4 / 6 bar | 100 / 200 / 300 l/min |
| Dimensions A / Width / C / D / E / F | 65 / 36 / 113 / 90 / 16 / 9 mm |
| Thread | G 1/4" |
| Weight | 0.76 kg |
| Maximum operating temperature | 150°C |
