Explore performance details, construction highlights, applications, and technical information in one clear overview.
The APEM Panel Switches PBAM1AF3002 is a robust, non-illuminated autoswitch designed for demanding industrial environments. With a life expectancy of 50 million cycles, IP68 and IP69K sealing, and operating within -40°C to +75°C, this switch ensures reliable performance in harsh conditions. Ideal for applications requiring high durability and electrical safety.
The APEM Panel Switches PBAM1AF3002 is a high-reliability, non-illuminated autoswitch engineered for industrial use. This switch delivers exceptional durability with a life expectancy of 50 million cycles, making it suitable for continuous operation in demanding environments. Its robust sealing to IP68 (IEC 60529) and IP69K (DIN 40050-9) standards ensures protection against dust, water, and high-pressure cleaning, while the operating temperature range of -40°C to +75°C (-40°F to +167°F) accommodates extreme conditions. The switch features a 1A 24V AC/DC rating, low operating force (6-12 N), and a compact 2.5mm height, providing precise control in critical industrial applications.
The PBAM1AF3002 operates within a 1A 24V AC/DC rating, suitable for resistive loads. It features a switch resistance of 10 Ω max when ON and 5 MΩ min when OFF, ensuring precise electrical control. The switch consumes 20 mA of LED current (non-illuminated) and requires an operating force of 6 to 12 N for reliable actuation.
Engineered for extreme conditions, the switch maintains performance across a temperature range of -40°C to +75°C (-40°F to +167°F). Its IP68 and IP69K certifications (per IEC 60529 and DIN 40050-9) provide exceptional protection against dust, water immersion, and high-pressure cleaning, making it ideal for industrial settings where environmental resilience is critical.
With a compact height of 2.5 mm, the switch features flying leads for easy terminal connection. The bushing diameters (16 mm, 19 mm, 22 mm, or 30 mm) allow for versatile mounting options, while the green anodised finish ensures durability and visual clarity in industrial environments.
The switch delivers a life expectancy of 50 million cycles, ensuring long-term reliability in high-traffic applications. Its low operating force (6-12 N) and minimal torque requirements (1.5 Nm min. to 10 Nm max.) facilitate smooth operation without excessive mechanical stress.
| Feature | Specification |
|---|---|
| Life expectancy | 50 million cycles LED consumption : 20 mA Switch resistance ON : 10 Ω max. Switch resistance OFF : 5 MΩ min. |
| Sealing | IP68 per IEC 60529, IP69K per DIN 40050-9 (switches mounted on panel) |
| Operating force | 6 to 12 N |
| Torque | 1.5 Nm min. - 10 Nm max Bushing diameter 16 (.630), 19 (.748), 22 (.866) or 30 mm (1.181) Sealed to IP68 and IP69K (switches mounted on panel) Easy to clean metal surface Very long life expectancy Ring illumination: flus |
| Bushing Operator | Operator Height 2.5mm(0.98in) Non-Illuminated |
| Ratings | 1A 24V AC/DC |
| Operating temperature | -40 °C to +75 °C (-40 °F to +167 °F) |
| Max. current/voltage rating with resistive load | 1 A 24 VAC/DC Switch resistance ON : 10 Ω max. Switch resistance OFF : 5 MΩ min. |
| Colors Materials | Green Anodised,LED Voltage:Non-Illuminated |
| Electrical Functions | No Pulse |
| Feature | Specification |
|---|---|
| Height | 2.5mm |
The APEMPanel Switches PBAM1AF3002 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Life expectancy | 50 million cycles LED consumption : 20 mA Switch resistance ON : 10 Ω max. Switch resistance OFF : 5 MΩ min. |
| Sealing | IP68 per IEC 60529, IP69K per DIN 40050-9 (switches mounted on panel) |
| Operating force | 6 to 12 N |
| Torque | 1.5 Nm min. - 10 Nm max Bushing diameter 16 (.630), 19 (.748), 22 (.866) or 30 mm (1.181) Sealed to IP68 and IP69K (switches mounted on panel) Easy to clean metal surface Very long life expectancy Ring illumination: flus |
| Bushing Operator | Operator Height 2.5mm(0.98in) Non-Illuminated |
| Ratings | 1A 24V AC/DC |
| Operating temperature | -40 °C to +75 °C (-40 °F to +167 °F) |
| Max. current/voltage rating with resistive load | 1 A 24 VAC/DC Switch resistance ON : 10 Ω max. Switch resistance OFF : 5 MΩ min. |
| Colors Materials | Green Anodised,LED Voltage:Non-Illuminated |
| Electrical Functions | No Pulse |
| Feature | Specification |
|---|---|
| Height | 2.5mm |
