The APEM Panel Switches MTG92AD4 is a robust autoswitch designed for industrial applications. Featuring an ON/OFF/ON electrical function, this switch delivers reliable performance with a minimal load of 50 mA at 10 VDC for A contacts, ensuring precise control in demanding environments. Its exceptional insulation resistance of 1,000 MΩ min. at 500 VDC and dielectric strength of 1,500 Vrms 50Hz min. between terminals and frame make it suitable for high-voltage industrial systems.
The APEM MTG92AD4 Panel Switch is a high-reliability autoswitch engineered for industrial control systems. This switch provides a simple yet effective ON/OFF/ON electrical function, enabling precise switching operations in critical applications. With a panel thickness of 11.5 mm max., it is designed to withstand harsh operating conditions from -40 °C to +85 °C. The MTG92AD4 delivers consistent performance with minimal contact resistance (10 mΩ max.), low contact bounce (2ms max.), and high electrical life (50,000 cycles at full load), making it ideal for environments requiring dependable switching without frequent maintenance.
The MTG92AD4 delivers reliable electrical performance with a contact resistance of 10 mΩ max. and minimal load requirements of 50 mA at 10 VDC for A contacts. Its electrical life at full load reaches 50,000 cycles, ensuring long-term durability in industrial applications. The switch also features a contact bounce of 2ms max., minimizing operational delays during switching transitions.
Engineered for extreme conditions, the MTG92AD4 operates within a temperature range of -40 °C to +85 °C, making it suitable for both cold and hot industrial environments. Its robust construction ensures consistent performance across a wide range of operational temperatures without degradation.
With an insulation resistance of 1,000 MΩ min. at 500 VDC and dielectric strength of 1,500 Vrms 50Hz min. between terminals and frame, the MTG92AD4 provides exceptional protection against electrical faults. This ensures safe operation in high-voltage industrial systems while maintaining compliance with stringent safety standards.
The switch is designed for mechanical durability with a low-level or mechanical life of 100,000 cycles, ensuring long-term reliability even under frequent switching operations. Its compact panel thickness of 11.5 mm max. allows for seamless integration into tight industrial panels without compromising structural integrity.
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. between terminals, 1,500 Vrms 50Hz min. between terminals and frame Contact bounce : 2ms max. Electrical life at full load : 50,000 cycles Minimal load:- A contacts: 50 mA 10 VDC- AD and CD contacts |
| Panel thickness | 11.5 mm (.452) max. |
| Operating temperature | -40 °C to +85 °C Low level or mechanical life : 100,000 cycles |
| Electrical Functions | ON OFF ON |
The APEMPanel Switches MTG92AD4 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. between terminals, 1,500 Vrms 50Hz min. between terminals and frame Contact bounce : 2ms max. Electrical life at full load : 50,000 cycles Minimal load:- A contacts: 50 mA 10 VDC- AD and CD contacts |
| Panel thickness | 11.5 mm (.452) max. |
| Operating temperature | -40 °C to +85 °C Low level or mechanical life : 100,000 cycles |
| Electrical Functions | ON OFF ON |
