APEM Autoswitches Switches and Pushbutton

Panel Switches MT72AD3 – Autoswitches UAE

MT72AD3 MT72AD3 Panel Switch: A durable rocker switch designed for tough environments, ensuring seamless control of lights, motors, and machinery. Reliable and efficient for all electrical needs.

Brand APEM
Category Autoswitches
Subcategory Switches and Pushbutton

Interested in this product? Panel Switches MT72AD3

Product insights

Everything you need to evaluate this product

Explore performance details, construction highlights, applications, and technical information in one clear overview.

Quality assured Technical details Industrial use Expert support

Panel Switches MT72AD3

MT72AD3 MT72AD3 Panel Switch: A durable rocker switch designed for tough environments, ensuring seamless control of lights, motors, and machinery. Reliable and efficient for all electrical needs. Select Quantity

Key Features

Insulation resistance: 1,000 MΩ min. at 500 VDC
Dielectric strength: 1,000 Vrms 50 Hz min. between terminals, 1,500 Vrms 50Hz min. between terminals and frame Contact bounce : 2ms max. Electrical life at full load : 50,000 cycles Minimal load:- A contacts: 50 mA 10 VDC- AD and CD contacts
Panel thickness: 11.5 mm (.452) max.
Initial contact resistance: 10 mΩ max.
Operating temperature: -40 °C to +85 °C Low level or mechanical life : 100,000 cycles
Finish: Bright Chrome
Electrical Functions: MOM OFF MOM

Feature	Specification
Insulation resistance	1,000 MΩ min. at 500 VDC
Dielectric strength	1,000 Vrms 50 Hz min. between terminals, 1,500 Vrms 50Hz min. between terminals and frame Contact bounce : 2ms max. Electrical life at full load : 50,000 cycles Minimal load:- A contacts: 50 mA 10 VDC- AD and CD contacts
Panel thickness	11.5 mm (.452) max.
Operating temperature	-40 °C to +85 °C Low level or mechanical life : 100,000 cycles
Electrical Functions	MOM OFF MOM
