IRR1F422L0Y IRR1F422L0Y Panel Switch: sleek round actuator, easy ON/OFF operation, flying leads for installation, silver gold plated contacts, 100 mA max current, 24 VDC voltage rating. Select Quantity
| Feature | Specification |
|---|---|
| Insulation resistance | 1 GΩ min. at 500 VDC |
| Panel thickness | 8 mm (.314) max. |
| Total travel | 2.5 mm (.098) +/- 0,3 mm Typical |
| Initial contact resistance | 100 mΩ max. |
| force | 5 N |
| LED Color | Yellow,Actuator Colors:Black,Bushing Bezel:Black Standard,Contact Materials:Silver (Gold-Plated),Illumination:Central Lens |
| Feature | Specification |
|---|---|
| sealing | IP67 according to IEC 60529 Shock resistance: 100 g according to IEC 512-4, test 6c Vibration resistance: 10-500Hz - 10 g according to IEC 512-4, test 6d Salt spray: IEC 512-6, test 11f |
| Operating temperature | -40 °C to +85 °C(-40 °F to 185 °F) Shock resistance: 100 g according to IEC 512-4, test 6c Vibration resistance: 10-500Hz - 10 g according to IEC 512-4, test 6d Salt spray: IEC 512-6, test 11f |
| Torque | 0.8 Nm max. applied to nut Soldering: 320 °C max. for 3 sec. Soldering: 320 °C max. for 3 sec. Latching action models Sealed to IP67 Illuminated or non-illuminated Flat round actuator for optional marking Sealed to IP67 |
| operating force | 5 N +/- 2 N Low level or mechanical life: 200,000 cycles |
| Electrical Functions | ON OFF |
| Feature | Specification |
|---|---|
| Insulation resistance | 1 GΩ min. at 500 VDC |
| Panel thickness | 8 mm (.314) max. |
| Total travel | 2.5 mm (.098) +/- 0,3 mm Typical |
