The APEM Panel Switches FPCR3C1428B1253 is a snap-in 1-pole autoswitch designed for industrial applications. Featuring bright chrome bezel, green LED indicators, and 12VDC compatibility, it delivers reliable operation with 1 million cycles for momentary models and 200,000 cycles for latching models. This lightweight switch supports solder lug terminals and operates within -40°C to +75°C temperature ranges.
The APEM Panel Switches FPCR3C1428B1253 is a robust, snap-in 1-pole autoswitch engineered for demanding industrial environments. With a bright chrome bezel, green LED status indicator, and 12VDC compatibility, this switch provides precise control for low-voltage circuits. Its exceptional electrical life—up to 1 million cycles for momentary models with gold-plated contacts—ensures long-term reliability in critical applications. The switch operates within a wide temperature range of -40°C to +75°C and features a compact 2.8 mm ± 0.5 mm total travel, making it ideal for space-constrained panels.
The FPCR3C1428B1253 delivers reliable electrical performance with a maximum contact resistance of 50 mΩ and an insulation resistance of 1 GΩ min. at 500 VDC. It supports 12VDC loads with silver contacts rated for 4 A and gold-plated contacts for 200 mA, ensuring compatibility with low-voltage systems while maintaining high durability.
Engineered for industrial use, this switch withstands 8 N ± 2 N operating force and 2 Nm max. torque. Its snap-in design with 1.5–2.5 mm panel thickness (with or without gasket) ensures secure installation in standard panels, while the 2.8 mm ± 0.5 mm total travel provides smooth operation without excessive wear.
With electrical life ratings of up to 1 million cycles for momentary models and 200,000 cycles for latching models, the FPCR3C1428B1253 ensures extended service life. The switch maintains performance across a wide temperature range (-40°C to +75°C), making it suitable for harsh environments without compromising functionality.
The switch features pad-printed or laser-etched symbols for clear identification and a lightweight design. Its snap-in version accommodates standard panel thicknesses (1.5–2.5 mm), while the threaded bushing option provides flexibility for custom mounting. Solder lug terminals ensure robust electrical connections without additional hardware.
| Feature | Specification |
|---|---|
| Insulation resistance | 1 GΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. Electrical life at full load :- Momentary models : 1 million cycles (gold plated contacts) 400,000 cycles (silver contacts)- Latching models : 200,000 cycles Electrical life at full load :- Momentar |
| Panel thickness | - Snap-in version : 1.5 (.059) to 2 mm (.078) with panel gasket 2 (.078) to 2.5 mm (.885) without panel gasket- Threaded bushing version : 1(.039) to 9 mm (.354) max. |
| Total travel | 2.8 mm ± 0.5 mm Typical |
| Torque | 2 Nm max. applied to nut Full actuator or symbol illumination Snap-in and threaded bushing models Large but lightweight Pad printed or laser etched symbols Snap-in and threaded bushing models Large but lightweight Pad pr |
| Electrical Functions | Normally Open (NO) Bezel Colour: Bright Chrome Led Control And No Of Poles: Independent 1-Pole Led Resistors: 12VDC Resistor Markings: Laser Model: Snap-in 30mm |
| Operating temperature | -40 °C to +75 °C |
| LED Color | Green,Actuator Colors:Black,Actuators:Round, Curved,Bezel Color:Bright Chrome,Led Control And No Of Poles:Independent 1-Pole,Led Resistors:12VDC Resistor,Markings:Laser,Model:Snap-in 30mm |
| Max. current/voltage rating with resistive load | - silver contacts (code 2) : 4 A 12 VDC- gold plated contacts (code 4) : 200 mA 12 VDC |
The APEMPanel Switches FPCR3C1428B1253 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Insulation resistance | 1 GΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. Electrical life at full load :- Momentary models : 1 million cycles (gold plated contacts) 400,000 cycles (silver contacts)- Latching models : 200,000 cycles Electrical life at full load :- Momentar |
| Panel thickness | - Snap-in version : 1.5 (.059) to 2 mm (.078) with panel gasket 2 (.078) to 2.5 mm (.885) without panel gasket- Threaded bushing version : 1(.039) to 9 mm (.354) max. |
| Total travel | 2.8 mm ± 0.5 mm Typical |
| Torque | 2 Nm max. applied to nut Full actuator or symbol illumination Snap-in and threaded bushing models Large but lightweight Pad printed or laser etched symbols Snap-in and threaded bushing models Large but lightweight Pad pr |
| Electrical Functions | Normally Open (NO) Bezel Colour: Bright Chrome Led Control And No Of Poles: Independent 1-Pole Led Resistors: 12VDC Resistor Markings: Laser Model: Snap-in 30mm |
| Operating temperature | -40 °C to +75 °C |
| LED Color | Green,Actuator Colors:Black,Actuators:Round, Curved,Bezel Color:Bright Chrome,Led Control And No Of Poles:Independent 1-Pole,Led Resistors:12VDC Resistor,Markings:Laser,Model:Snap-in 30mm |
| Max. current/voltage rating with resistive load | - silver contacts (code 2) : 4 A 12 VDC- gold plated contacts (code 4) : 200 mA 12 VDC |
