The APEM Panel Switches 96..NZ132CDBX601U1720 is a single pole, normally closed (NC) autoswitch designed for industrial applications. This epoxy sealed terminal switch features quick connect terminals, with a maximum current rating of 1 A for silver contacts and 100 mA for gold-plated contacts under 30 VDC. It operates reliably across temperatures from -30°C to +65°C and meets stringent electrical safety standards including 1,000 Vrms dielectric strength.
The APEM Panel Switches 96..NZ132CDBX601U1720 is a robust, epoxy sealed single pole, normally closed (NC) autoswitch engineered for demanding industrial environments. This switch delivers precise electrical control with quick connect terminals, ensuring reliable operation in harsh conditions. Its exceptional electrical life of 250,000 cycles and wide temperature range from -30°C to +65°C make it ideal for applications requiring consistent performance without frequent maintenance. The switch is designed to meet strict safety standards, including 1,000 MΩ insulation resistance at 500 VDC and 1,000 Vrms dielectric strength for terminal-to-terminal and terminal-to-frame isolation.
The APEM Panel Switches 96..NZ132CDBX601U1720 delivers precise electrical control with a 1,000 MΩ minimum insulation resistance at 500 VDC and 1,000 Vrms 50 Hz dielectric strength between terminals. It also provides 1,500 Vrms 50 Hz dielectric strength between terminals and the metal frame, ensuring robust protection against electrical faults. The switch features an initial contact resistance of 50 mΩ maximum, minimizing voltage drop during operation.
Engineered for extreme conditions, this switch operates reliably across a wide temperature range from -30°C to +65°C. Its epoxy sealing and quick connect terminals ensure long-term performance in harsh industrial environments without degradation of electrical properties.
The switch supports maximum current ratings of 1 A for silver contacts and 100 mA for gold-plated contacts under 30 VDC. This distinction allows for precise selection based on contact material requirements, ensuring optimal performance for both high and low current applications.
With a 9.4 mm (0.370 in) cap size and quick connect terminals, the switch is designed for straightforward installation. The epoxy sealing provides protection against environmental factors, while the quick connect bushing ensures secure terminal connections without the need for additional tools.
| Feature | Specification |
|---|---|
| Sealing | Epoxy Sealed Terminals Standard,Cap:9.4 mm(0.370 in),Terminals Case And Bushing:Quick Connect |
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. between terminals1,500 Vrms 50 Hz min. between terminals and frame |
| Operating temperature | -30 °C to +65 °C |
| Max. current/voltage rating with resistive load | - silver contact (A) : 1 A 30 VDC- gold plated contacts (CD) : 100 mA 30 VDC |
| Electrical Functions | Normally Closed (NC),Poles:Single Pole |
| Feature | Specification |
|---|---|
| Torque | 1.25 Nm (.922 Ft.lb) max. applied to nut |
The APEMPanel Switches 96..NZ132CDBX601U1720 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Sealing | Epoxy Sealed Terminals Standard,Cap:9.4 mm(0.370 in),Terminals Case And Bushing:Quick Connect |
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. between terminals1,500 Vrms 50 Hz min. between terminals and frame |
| Operating temperature | -30 °C to +65 °C |
| Max. current/voltage rating with resistive load | - silver contact (A) : 1 A 30 VDC- gold plated contacts (CD) : 100 mA 30 VDC |
| Electrical Functions | Normally Closed (NC),Poles:Single Pole |
| Feature | Specification |
|---|---|
| Torque | 1.25 Nm (.922 Ft.lb) max. applied to nut |
