The APEM Panel Switches 96..N32CDBX601U480 is a single-pole, normally closed (NC) autoswitch designed for industrial applications. This epoxy-sealed switch features solder lug terminals, 1,000 MΩ insulation resistance at 500 VDC, and 250,000 cycle electrical life. Ideal for reliable operation in environments ranging from -30°C to +65°C.
The APEM Panel Switches 96..N32CDBX601U480 is a robust, epoxy-sealed single-pole, normally closed (NC) autoswitch engineered for demanding industrial environments. With a maximum operating temperature range of -30°C to +65°C, this switch delivers exceptional reliability through its 1,000 MΩ insulation resistance at 500 VDC and 250,000 cycle electrical life. The switch is designed for applications requiring precise control with silver contacts rated for 1 A at 30 VDC and gold-plated contacts rated for 100 mA at 30 VDC, ensuring compatibility with a wide range of resistive loads.
The APEM Panel Switches 96..N32CDBX601U480 features precise electrical characteristics for reliable operation. It maintains 1,000 MΩ insulation resistance at 500 VDC, ensuring robust isolation between terminals. The dielectric strength is 1,000 Vrms 50 Hz between terminals and 1,500 Vrms 50 Hz between terminals and the frame, providing high immunity to electrical stress. Initial contact resistance is limited to 50 mΩ max, ensuring minimal voltage drop during operation.
Engineered for extreme conditions, this switch operates effectively across a wide temperature range from -30°C to +65°C. The epoxy sealing protects terminals from environmental factors, maintaining performance in harsh industrial settings without compromising reliability.
The switch supports two contact types: silver contacts rated for 1 A at 30 VDC and gold-plated contacts rated for 100 mA at 30 VDC with resistive loads. This dual-rating capability allows flexibility in applications requiring different current levels while ensuring long-term durability.
| Feature | Specification |
|---|---|
| Sealing | Epoxy Sealed Terminals Standard,Cap:10 mm (0.393in) Standard,Terminals Case And Bushing:Solder Lug Terminals |
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. between terminals1,500 Vrms 50 Hz min. between terminals and frame |
| Operating temperature | -30 °C to +65 °C |
| Max. current/voltage rating with resistive load | - silver contact (A) : 1 A 30 VDC- gold plated contacts (CD) : 100 mA 30 VDC |
| Electrical Functions | Normally Closed (NC),Poles:Single Pole |
| Feature | Specification |
|---|---|
| Torque | 1.25 Nm |
The APEMPanel Switches 96..N32CDBX601U480 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Sealing | Epoxy Sealed Terminals Standard,Cap:10 mm (0.393in) Standard,Terminals Case And Bushing:Solder Lug Terminals |
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 1,000 Vrms 50 Hz min. between terminals1,500 Vrms 50 Hz min. between terminals and frame |
| Operating temperature | -30 °C to +65 °C |
| Max. current/voltage rating with resistive load | - silver contact (A) : 1 A 30 VDC- gold plated contacts (CD) : 100 mA 30 VDC |
| Electrical Functions | Normally Closed (NC),Poles:Single Pole |
| Feature | Specification |
|---|---|
| Torque | 1.25 Nm |
