The APEM Panel Switches 5539A-4N is a single pole autoswitch designed for ON OFF ON electrical control. Featuring epoxy sealed terminals, UL and CSA approvals, and a 4N force rating, this versatile switch ensures reliable operation in industrial applications with precise paddle-compatible levers for accurate switching.
The APEM Panel Switches 5539A-4N is a single pole autoswitch engineered for precise ON OFF ON electrical control in industrial environments. This switch delivers robust performance with epoxy sealed terminals, UL and CSA certifications, and a 4N force rating for reliable operation. Its paddle-compatible levers ensure accurate switching in demanding applications, while the specialized body design provides enhanced creepage distance and air gap for safety and durability.
The APEM Panel Switches 5539A-4N operates with a dielectric strength of 2,000 Vrms 50 Hz min. between poles and between terminals and frame, and 1,000 Vrms 50 Hz min. between terminals. This ensures high electrical isolation and safety in industrial applications. The switch supports resistive loads and features a 4N force rating for precise lever operation.
UL and CSA approvals are standard for the APEM Panel Switches 5539A-4N, ensuring compliance with international safety standards. The switch also meets VDE marking requirements, providing reliable performance in regulated environments.
The switch is designed for easy mounting with paddle-compatible levers, ensuring precise control in industrial settings. A U721 connector is compulsory if the panel is not metallic or not connected to ground, enhancing electrical safety during installation.
| Feature | Specification |
|---|---|
| Dielectric strength | 2,000 Vrms 50 Hz min. between poles and between terminals and frame1,000 Vrms 50 Hz min. between terminals Special body for increased creepage distance and air gap : 3 mm (.118) Current/voltage rating with resistive load |
| Electrical Functions | ON OFF ON |
The APEMPanel Switches 5539A-4N is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Dielectric strength | 2,000 Vrms 50 Hz min. between poles and between terminals and frame1,000 Vrms 50 Hz min. between terminals Special body for increased creepage distance and air gap : 3 mm (.118) Current/voltage rating with resistive load |
| Electrical Functions | ON OFF ON |
