The APEM Panel Switches 2647LHA232000L0 is a double-pole autoswitch designed for industrial applications. Featuring silver contacts with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load, this switch offers robust performance across operating temperatures from -20°C to +85°C for standard contacts. Available in plain, V-shaped, or concave rocker shapes with multiple color options, it meets UL, CSA, VDE, and NF (EN 61058-1) standards for safety and reliability.
The APEM Panel Switches 2647LHA232000L0 is a high-performance double-pole autoswitch engineered for demanding industrial environments. This switch delivers precise control with silver contacts that maintain low resistance (10 mΩ max) and exceptional durability through 10,000 cycles at full load. Its wide operating temperature range (-20°C to +85°C for standard contacts) ensures reliable operation in extreme conditions, while the three available rocker shapes (plain, V-shaped, or concave) and multiple color options provide flexibility for integration into diverse control panels. The switch meets stringent international safety standards including UL, CSA, VDE, and NF (EN 61058-1) to guarantee safe electrical performance and compliance with global regulations.
The APEM Panel Switches 2647LHA232000L0 delivers robust electrical characteristics with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load. It maintains high insulation resistance (1,000 MΩ min. at 500 VDC) and dielectric strength (2,500 Vrms 50 Hz min. between terminals), ensuring reliable operation under demanding electrical conditions.
Engineered for versatility across industrial environments, this switch operates within a temperature range of -20°C to +85°C for standard silver contacts. The switch also features a protective frame with a guard on 2600LP models, enhancing safety in high-risk applications while maintaining compliance with international standards.
Available in three distinct rocker shapes (plain, V-shaped, or concave) and multiple color options, the switch accommodates various panel thicknesses (0.8 mm to 4 mm). Its double-pole configuration ensures precise control of two circuits, while the screw clamp mounting provides secure installation.
The APEM Panel Switches 2647LHA232000L0 meets stringent international safety standards including UL, CSA, VDE, and NF (EN 61058-1) approval. This certification ensures the switch is safe for use in industrial applications and complies with global electrical safety regulations.
| Feature | Specification |
|---|---|
| Configuration | double pole configuration |
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | MOM OFF MOM |
| Mounting | Screw Clamp |
The APEMPanel Switches 2647LHA232000L0 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Configuration | double pole configuration |
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | MOM OFF MOM |
| Mounting | Screw Clamp |
