The 2646LP/2A234001L0 Panel Switch features a sleek design, easy installation, and double pole configuration for reliable ON ON circuit control. Ideal for various electrical applications. Select Quantity
| Feature | Specification |
|---|---|
| Configuration | double pole configuration |
| Feature | Specification |
|---|---|
| Configuration | double pole configuration |
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | ON ON |
| Mounting | Solder Lug Quick Connect |
