The APEM Panel Switches 2646LH/2A237000L0 is a double-pole autoswitch designed for industrial applications. Featuring silver contacts with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load, this switch offers robust performance in demanding environments. With UL, CSA, VDE, and NF (EN 61058-1) approvals, it ensures compliance for critical systems.
The APEM Panel Switches 2646LH/2A237000L0 is a double-pole autoswitch engineered for reliable operation in industrial settings. This switch utilizes silver contacts with a maximum initial contact resistance of 10 mΩ and delivers 10,000 cycles of electrical life at full load. Its robust construction includes a 0.8 mm to 4 mm panel thickness, three rocker shapes (plain, V-shaped, concave), and various color options. The switch meets stringent international standards including UL, CSA, VDE, and NF (EN 61058-1) for safety and performance in electrical applications.
The APEM Panel Switches 2646LH/2A237000L0 delivers exceptional electrical performance with a minimum insulation resistance of 1,000 MΩ at 500 VDC and dielectric strength of 2,500 Vrms 50 Hz between terminals. This ensures reliable operation under high-voltage conditions while maintaining safety margins.
Engineered for diverse operational environments, the switch supports an operating temperature range of -20 °C to +85 °C for silver contacts. This wide range makes it suitable for both extreme cold and high-heat industrial applications without compromising performance.
Constructed with a 0.8 mm to 4 mm panel thickness, the switch accommodates three rocker shapes (plain, V-shaped, concave) and multiple color options. The frame includes a protection guard on 2600LP models, enhancing safety and durability in high-traffic industrial settings.
The APEM Panel Switches 2646LH/2A237000L0 meets international safety standards including UL, CSA, VDE, and NF (EN 61058-1). This certification ensures the switch is safe for use in critical electrical systems and complies with global regulatory requirements.
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | ON ON |
| Mounting | Solder Lug Quick Connect |
The APEMPanel Switches 2646LH/2A237000L0 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | ON ON |
| Mounting | Solder Lug Quick Connect |
