The APEM Panel Switches 2646LH/2A212000L0 is a double-pole autoswitch designed for industrial applications. Featuring silver contacts with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load, this switch offers robust performance in demanding environments. With UL, CSA, VDE, and NF (EN 61058-1) approvals, it ensures compliance for critical systems.
The APEM Panel Switches 2646LH/2A212000L0 is a double-pole autoswitch engineered for reliable operation in industrial settings. This switch delivers precise control with silver contacts that maintain low resistance (10 mΩ max) and withstand 10,000 cycles at full load. Its robust construction includes a 0.8 mm to 4 mm panel thickness, multiple rocker shapes (plain, V-shaped, concave), and optional illumination, making it suitable for applications requiring high durability and safety compliance. The switch meets stringent international standards including UL, CSA, VDE, and NF (EN 61058-1) for electrical safety.
The Panel Switches 2646LH/2A212000L0 delivers reliable electrical performance with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load. It features high insulation resistance (1,000 MΩ min. at 500 VDC) and dielectric strength (2,500 Vrms 50 Hz min. between terminals), ensuring stable operation under demanding electrical conditions.
Designed for industrial environments, this switch operates within a temperature range of -20 °C to +85 °C for silver contacts.
The APEM Panel Switches 2646LH/2A212000L0 meets international safety standards including UL, CSA, VDE, and NF (EN 61058-1). This certification ensures the switch is safe for use in critical applications, providing peace of mind for engineers and technicians.
Available in three rocker shapes (plain, V-shaped, concave) and multiple colors, the switch features a frame with optional protection guard on 2600LP models. It supports solder lug quick connect mounting and is available with or without illumination, catering to specific application needs.
| Feature | Specification |
|---|---|
| Configuration | double pole configuration |
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | ON ON |
| Mounting | Solder Lug Quick Connect |
The APEMPanel Switches 2646LH/2A212000L0 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Configuration | double pole configuration |
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | ON ON |
| Mounting | Solder Lug Quick Connect |
