Explore performance details, construction highlights, applications, and technical information in one clear overview.
The APEM Panel Switches 2645LH/2A235000L0 is a double-pole autoswitch designed for industrial applications. Featuring silver contacts with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load, this switch offers robust performance in demanding environments. With UL, CSA, VDE, and NF (EN 61058-1) approvals, it ensures compliance for critical industrial systems.
The APEM Panel Switches 2645LH/2A235000L0 is a high-reliability double-pole autoswitch engineered for industrial control panels. This switch delivers precise switching performance with silver contacts that maintain low resistance (10 mΩ max) and withstand 10,000 cycles at full load. Its robust construction includes a 0.8 mm to 4 mm panel thickness, three rocker shapes (plain, V-shaped, concave), and optional illumination. The switch meets stringent international standards including UL, CSA, VDE, and NF (EN 61058-1) for safety and performance in industrial environments.
The APEM Panel Switches 2645LH/2A235000L0 delivers reliable electrical performance with a minimum insulation resistance of 1,000 MΩ at 500 VDC and dielectric strength of 2,500 Vrms 50 Hz between terminals. This ensures robust protection against electrical faults and high-voltage transients in industrial settings.
Engineered for diverse operating conditions, the switch supports an operating temperature range of -20 °C to +85 °C for silver contacts, making it suitable for extreme environments. The panel thickness ranges from 0.8 mm to 4 mm (.031 to .157), accommodating various installation requirements.
The switch features a durable frame with optional protection guard on 2600LP models. It is certified to UL, CSA, VDE, and NF (EN 61058-1) standards, ensuring compliance with international safety regulations for industrial applications.
Available in three rocker shapes (plain, V-shaped, concave) and multiple colors, the switch supports both illuminated and non-illuminated options. The double-pole design with MOM ON functionality provides precise control for critical industrial systems.
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | MOM ON |
| Mounting | Solder Lug Quick Connect |
The APEMPanel Switches 2645LH/2A235000L0 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | MOM ON |
| Mounting | Solder Lug Quick Connect |
