The APEM Panel Switches 2645LH/2A232000L0 is a double-pole, double-throw (MOM ON) autoswitch designed for industrial applications. Featuring silver contacts, a black plain frame, and concave rocker shape, this switch offers robust electrical performance with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load. Its UL, CSA, VDE, and NF (EN 61058-1) approvals ensure compliance for demanding environments.
The APEM Panel Switches 2645LH/2A232000L0 is a precision-engineered double-pole autoswitch designed for reliable operation in industrial control systems. This switch features silver contacts with a black plain frame, concave rocker shape, and solder lug quick connect terminals. It delivers exceptional electrical performance with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load. The switch meets stringent international standards including UL, CSA, VDE, and NF (EN 61058-1) for safety and reliability in critical applications.
The APEM Panel Switches 2645LH/2A232000L0 delivers robust electrical performance with an initial contact resistance of 10 mΩ max and electrical life of 10,000 cycles at full load. It features high insulation resistance (1,000 MΩ min. at 500 VDC) and dielectric strength (2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel) to ensure safe operation under demanding electrical conditions.
Engineered for diverse industrial environments, this switch operates within a temperature range of -20 °C to +85 °C for silver contacts. The panel thickness ranges from 0.8 mm to 4 mm (.031 to .157), accommodating various installation requirements while maintaining structural integrity.
The APEM Panel Switches 2645LH/2A232000L0 meets international safety standards including UL, CSA, VDE, and NF (EN 61058-1) approvals. This ensures compliance with global regulations for low-voltage equipment, making it suitable for applications requiring stringent safety certifications.
With a black plain frame and concave rocker shape, this switch provides a durable and ergonomic design. The solder lug quick connect terminals allow for easy installation, while the optional frame with protection guard (available on 2600LP models) enhances safety in high-risk environments.
| Feature | Specification |
|---|---|
| Configuration | Double Pole configuration |
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | MOM ON |
The APEMPanel Switches 2645LH/2A232000L0 is presented using the documented product characteristics available for this model.
| Feature | Specification |
|---|---|
| Configuration | Double Pole configuration |
| Feature | Specification |
|---|---|
| Insulation resistance | 1,000 MΩ min. at 500 VDC |
| Dielectric strength | 2,500 Vrms 50 Hz min. between terminals, 3,000 Vrms 50 Hz min. between terminals and metal panel |
| Operating temperature | - silver contacts (A) : -20 °C to +85 °C- silver plated contacts (C) : -10 °C to +55 °C |
| Panel thickness | 0.8 mm to 4 mm (.031 to .157) Three rocker shapes : plain, V-shaped or concave Various rocker colors Frame with protection guard on 2600LP models Illuminated or non-illuminated UL, CSA, VDE and NF (EN 61058-1) approved V |
| Electrical Functions | MOM ON |
