The APEM Panel Switches 1213C7/1 is a Switches and Pushbutton with documented product-specific characteristics including Plunger Colors: White; Torque: 1.5 Nm max. applied to nut; Panel thickness: 1.5 mm (.059) min., 4 mm (.157 max.).
| Feature | Specification |
|---|---|
| Torque | 1.5 Nm max. applied to nut |
| Panel thickness | 1.5 mm (.059) min. , 4 mm (.157 max.) |
| Total travel | Function 3: 1.7 mm (.067) +/- 0.3 mm Function 5: 1.3 mm (.051) +/- 0.3 mm |
| operating force | 6N +/- 2N |
| Max. current/voltage rating with resistive load | - silver contacts (A) : 4 A 250 VAC - 8 A 125 VAC - 4 A 24 VDC - 8 A 12 VDC- silver plated copper contacts (C) : 2 A 250 VAC - 3 A 125 VAC - 2 A 24 VDC - 3 A 12 VDC |
| Electrical Functions | Normally Open (NO) |
| Mounting | Solder Lug and Quick Connect Contact Materials: Copper (Silver-Plated) |
