Explore performance details, construction highlights, applications, and technical information in one clear overview.
L64C-2GP-EAN is a NORGREN configuration represented by Olympian Plus Oil fog lubricator, G1/4, 1l metal bowl closed. This product entry presents the listed configuration and model-specific technical information for selection and comparison.
The selected configuration is identified by Olympian Plus Oil fog lubricator, G1/4, 1l metal bowl closed. The principal recorded product data includes Media: Compressed air. Port Size: 1/4" ISO G. Drain Type: Closed bowl. Bowl Material: Aluminum alloy. Operating Temperature: -20 ... 80 °C, -4 ... 176 °F. Maximum Inlet Pressure: 17 bar, 246 psi. Lubricator Fog Type: Oil fog. Bowl Capacity: 1 l.
Flow: 25 dm3/s, 53 scfm. Materials - Body: Zinc alloy. Materials - Bowl: Aluminum alloy. Materials - Elastomers: Nitrile rubber (NBR). Country of Origin: Czechia. Range: L64C. Materials: cable Characteristics M/50/LSU/5V ● 5 m -20 to +80 °C PVC - M/50/LSU/CP ● 0,3 m with plug M8 -20 to +80 °C PVC - M/50/LSU/5U ● 5 m -20 to +80 °C PUR cable very flexible Model LED (Am- arelo) Cable length /. Materials: cable Ex identification M/50/EAP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/EAP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Am- arelo). Materials: cable Ex identification M/50/IOP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/IOP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Yellow) Cable length / plug - - - M/P73001/5 M/P73001/10 M/P73002/5. Materials: cable Characteristics QM/32/2 ● 2 m -20 … +80°C PVC - QM/32/P ● M12 Plug -20 … +80°C - - Model Diameter Atuador QM/31/032/22 Ø32 … 63 QM/31/080/22 Ø80 … 125 QM/31/160/22 Ø160 and 200 QM/31/250/22 Ø250. Gauge: ' B ' VA CUUM PORT (2X) AUXILIARY PORTS P R S 3X Ø ' D '. Gauge: P R F J K V U T.
Materials: Scale.
Languages 0 Basket
The listed product specifies Media as Compressed air. This stated value forms part of the model-specific product information.
For this configuration, Port Size is 1/4" ISO G. The value is retained as part of the product definition used for catalogue selection.
The product record includes Drain Type: Closed bowl. This is a configuration-specific value for the listed NORGREN model.
| Specification | Value |
|---|---|
| Media | Compressed air |
| Port Size | 1/4" ISO G |
| Drain Type | Closed bowl |
| Bowl Material | Aluminum alloy |
| Operating Temperature | -20 ... 80 °C, -4 ... 176 °F |
| Maximum Inlet Pressure | 17 bar, 246 psi |
| Lubricator Fog Type | Oil fog |
| Bowl Capacity | 1 l |
| Flow | 25 dm3/s, 53 scfm |
| Materials - Body | Zinc alloy |
| Materials - Bowl | Aluminum alloy |
| Materials - Elastomers | Nitrile rubber (NBR) |
| Country of Origin | Czechia |
| Range | L64C |
| Materials | cable Characteristics M/50/LSU/5V ● 5 m -20 to +80 °C PVC - M/50/LSU/CP ● 0,3 m with plug M8 -20 to +80 °C PVC - M/50/LSU/5U ● 5 m -20 to +80 °C PUR cable very flexible Model LED (Am- arelo) Cable length / |
| Materials | cable Ex identification M/50/EAP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/EAP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Am- arelo) |
| Materials | cable Ex identification M/50/IOP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/IOP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Yellow) Cable length / plug - - - M/P73001/5 M/P73001/10 M/P73002/5 |
| Materials | cable Characteristics QM/32/2 ● 2 m -20 … +80°C PVC - QM/32/P ● M12 Plug -20 … +80°C - - Model Diameter Atuador QM/31/032/22 Ø32 … 63 QM/31/080/22 Ø80 … 125 QM/31/160/22 Ø160 and 200 QM/31/250/22 Ø250 |
| Gauge | ' B ' VA CUUM PORT (2X) AUXILIARY PORTS P R S 3X Ø ' D ' |
| Gauge | P R F J K V U T |
| Materials | Scale |
