Explore performance details, construction highlights, applications, and technical information in one clear overview.
RM1L-1GD-NFV is a NORGREN Low flow miniature precision regulator, G1/8 configuration. The product entry brings together the stated connection, drainage, filtration and other technical characteristics for this exact listed model, so the content remains focused on the selected configuration.
The core configuration is defined by Country of Origin: Switzerland; Range: RM1; Gauge: ' B ' VA CUUM PORT (2X) AUXILIARY PORTS P R S 3X Ø ' D '; Gauge: P R F J K V U T. These values identify the product configuration and distinguish the listed arrangement from other configurations in the same range.
The available operating data specifies Media: Compressed air, Gases; Port Size: 1/8" ISO G; Outlet Pressure Adjustment: 0 ... 4 bar, 0 ... 60 psi; Operating Temperature: -5 ... 95 °C, 23 ... 203 °F; Adjustment: Adjusting screw; Maximum Inlet Pressure: 10 bar, 145 psi; Relieving/Non-Relieving: Non-relieving; Flow: 3.3 dm3/s, 7 scfm. Where pressure, temperature, flow, media, adjustment or drain information is provided, these values are included directly so the description remains aligned with the listed configuration.
The construction data records Materials - Body: Aluminum alloy; Materials - Bonnet: Polyphenylene sulfide (PPS); Materials - Elastomers: Fluoro-Polymer-Material (FPM); Materials: cable Characteristics M/50/LSU/5V ● 5 m -20 to +80 °C PVC - M/50/LSU/CP ● 0,3 m with plug M8 -20 to +80 °C PVC - M/50/LSU/5U ● 5 m -20 to +80 °C PUR cable very flexible Model LED (Am- arelo) Cable length /; Materials: cable Ex identification M/50/EAP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/EAP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Am- arelo); Materials: cable Ex identification M/50/IOP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/IOP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Yellow) Cable length / plug - - - M/P73001/5 M/P73001/10 M/P73002/5; Materials: cable Characteristics QM/32/2 ● 2 m -20 … +80°C PVC - QM/32/P ● M12 Plug -20 … +80°C - - Model Diameter Atuador QM/31/032/22 Ø32 … 63 QM/31/080/22 Ø80 … 125 QM/31/160/22 Ø160 and 200 QM/31/250/22 Ø250; Materials: Scale. These material details describe the components and material entries associated with the listed product rather than making broader durability or compatibility claims.
Languages 0 Basket Products Industries
| Specification | Value |
|---|---|
| Media | Compressed air, Gases |
| Port Size | 1/8" ISO G |
| Outlet Pressure Adjustment | 0 ... 4 bar, 0 ... 60 psi |
| Operating Temperature | -5 ... 95 °C, 23 ... 203 °F |
| Adjustment | Adjusting screw |
| Maximum Inlet Pressure | 10 bar, 145 psi |
| Relieving/Non-Relieving | Non-relieving |
| Flow | 3.3 dm3/s, 7 scfm |
| Materials - Body | Aluminum alloy |
| Materials - Bonnet | Polyphenylene sulfide (PPS) |
| Materials - Elastomers | Fluoro-Polymer-Material (FPM) |
| Country of Origin | Switzerland |
| Range | RM1 |
| Materials | cable Characteristics M/50/LSU/5V ● 5 m -20 to +80 °C PVC - M/50/LSU/CP ● 0,3 m with plug M8 -20 to +80 °C PVC - M/50/LSU/5U ● 5 m -20 to +80 °C PUR cable very flexible Model LED (Am- arelo) Cable length / |
| Materials | cable Ex identification M/50/EAP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/EAP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Am- arelo) |
| Materials | cable Ex identification M/50/IOP/5V ● 5 m PNP -20 to +80 °C PVC - M/50/IOP/CP ● 0,3 m with plug M8 PNP -20 to +80 °C PVC - Model LED (Yellow) Cable length / plug - - - M/P73001/5 M/P73001/10 M/P73002/5 |
| Materials | cable Characteristics QM/32/2 ● 2 m -20 … +80°C PVC - QM/32/P ● M12 Plug -20 … +80°C - - Model Diameter Atuador QM/31/032/22 Ø32 … 63 QM/31/080/22 Ø80 … 125 QM/31/160/22 Ø160 and 200 QM/31/250/22 Ø250 |
| Gauge | ' B ' VA CUUM PORT (2X) AUXILIARY PORTS P R S 3X Ø ' D ' |
| Gauge | P R F J K V U T |
| Materials | Scale |
