L07-200-MPQG is a NORGREN L07 Series micro fog lubricator, G1/4, closed bowl configuration.
Medium: Compressed air only. Maximum Inlet Pressure: 10 bar (145 psi) (Transparent bowl). Port Size: G1/8 or G1/4. Operating Temperature: Transparent bowl. Flow: Start point 0,24 dm3/s. Bowl Material: PC or Zinc alloy. Materials: Body: Zinc alloy. Maximum Supply Pressure: 10 bar (145 psi) (Transparent bowl) 17 bar (246 psi) (Metal bowl). Flow: Start point 0,24 dm3/s see below. Port Size: G1/8 or G1/4 Bowl volume: 31 ml. Operating Temperature: Transparent bowl -20 ... +50°C ( -4 ... +122°F) Metal bowl -20 ... +80°C ( -4 ... +176°F) Air supply must be dry enough to avoid ice formation at temperatures below +2°C (+35°F). Materials: Body: Zinc alloy Bowl: PC or Zinc alloy Sight-feed dome: PA Elastomers: NBR Technical features L07 Miniature lubticators - Port size: G1/8 & G1/4. Medium: Compressed air. Port Size: G1/4. Drain Type: Closed bowl. Bowl Material: Polycarbonate (PC). Operating Temperature: -20 ... 50 °C, -4 ... 122 °F. Maximum Inlet Pressure: 10 bar, 145 psi. Lubricator Fog Type: Micro fog. Bowl Capacity: 0.03 l. Flow: 6.7 dm3/s, 14 scfm. Materials - Body: Zinc alloy. Materials - Bowl: Polycarbonate (PC). Materials - Elastomers: Nitrile rubber (NBR). Dimensions - Height: 37 mm. Dimensions - Length: 120 mm. Dimensions - Width: 41 mm. Weight: 0.13 kg. Country of Origin: Mexico. Range: L07.
The selected configuration specifies Medium as Compressed air only. This value is part of the product definition and should be considered together with the other stated configuration details when selecting this model.
For this configuration, Maximum Inlet Pressure is 10 bar (145 psi) (Transparent bowl). The product content retains this value exactly as supplied for the selected model and does not substitute a value from another variant.
The product specification includes Port Size: G1/8 or G1/4. This is one of the technical characteristics that defines the configuration presented on this product page.
The stated Operating Temperature is Transparent bowl, forming part of the technical information associated with this exact product configuration.
| Specification | Value |
|---|---|
| Medium | Compressed air only |
| Maximum Inlet Pressure | 10 bar (145 psi) (Transparent bowl) |
| Port Size | G1/8 or G1/4 |
| Operating Temperature | Transparent bowl |
| Flow | Start point 0,24 dm3/s |
| Bowl Material | PC or Zinc alloy |
| Materials | Body: Zinc alloy |
| Maximum Supply Pressure | 10 bar (145 psi) (Transparent bowl) 17 bar (246 psi) (Metal bowl) |
| Flow | Start point 0,24 dm3/s see below |
| Port Size | G1/8 or G1/4 Bowl volume: 31 ml |
| Operating Temperature | Transparent bowl -20 ... +50°C ( -4 ... +122°F) Metal bowl -20 ... +80°C ( -4 ... +176°F) Air supply must be dry enough to avoid ice formation at temperatures below +2°C (+35°F) |
| Materials | Body: Zinc alloy Bowl: PC or Zinc alloy Sight-feed dome: PA Elastomers: NBR Technical features L07 Miniature lubticators - Port size: G1/8 & G1/4 |
| Medium | Compressed air |
| Port Size | G1/4 |
| Drain Type | Closed bowl |
| Bowl Material | Polycarbonate (PC) |
| Operating Temperature | -20 ... 50 °C, -4 ... 122 °F |
| Maximum Inlet Pressure | 10 bar, 145 psi |
| Lubricator Fog Type | Micro fog |
| Bowl Capacity | 0.03 l |
| Flow | 6.7 dm3/s, 14 scfm |
| Materials - Body | Zinc alloy |
| Materials - Bowl | Polycarbonate (PC) |
| Materials - Elastomers | Nitrile rubber (NBR) |
| Dimensions - Height | 37 mm |
| Dimensions - Length | 120 mm |
| Dimensions - Width | 41 mm |
| Weight | 0.13 kg |
| Country of Origin | Mexico |
| Range | L07 |
