The ELETTROTEC IF5V60/AM9 Visual Flow indicator is a precision flow measurement device designed for industrial applications. It operates within a temperature range of -10°C to +100°C, features FKM seals rated for +130°C (on request), and is available in anodized aluminum construction with a 15° maximum tilt tolerance. This flow indicator delivers accurate readings from 0.1 to 1 LPM at 136mm length and 40mm diameter, suitable for medium-pressure systems up to 0.60 bar.

Product Overview

The ELETTROTEC IF1V1/A Visual Flow indicator is a robust, precision flow measurement device engineered for reliable performance in demanding industrial environments. Designed to operate across a wide temperature range (-10°C to +100°C), this visual flow indicator provides clear, real-time flow rate visualization without requiring external power or complex instrumentation. Its compact form factor, with a maximum tilt tolerance of 15°, ensures accurate readings in both horizontal and slightly inclined installations. The IF5V60/AM9 - Visual Flow indicator is available in multiple configurations, including anodized aluminum housings for corrosion resistance and nickel-plated brass variants for enhanced durability in high-salinity applications.

Temperature and Environmental Tolerance

The IF1V1/A Visual Flow indicator is engineered to withstand extreme temperature variations, operating reliably between -10°C and +100°C. This wide temperature range ensures consistent performance in both cold and hot industrial environments, such as chemical processing plants, refineries, and HVAC systems. The device's robust construction also supports a maximum tilt angle of 15°, making it suitable for installations where pipelines may be slightly inclined without compromising accuracy.

Flow Measurement Capabilities

This visual flow indicator provides precise flow rate readings across a range of 0.1 to 1 LPM (liters per minute) for low-flow applications. The IF5V60/AM9 - Visual Flow indicator is designed to handle pressures up to 0.60 bar, making it ideal for systems where moderate pressure differentials are present. Its compact size (136mm length x 40mm diameter) and lightweight design (0.60 kg) ensure it integrates seamlessly into existing piping systems without adding significant bulk or weight.

Material and Construction Options

ELETTROTEC offers the IF1V1/A in two primary material configurations: anodized aluminum for general industrial use and nickel-plated brass for applications requiring resistance to corrosive environments. The aluminum version provides excellent corrosion resistance and is lightweight, while the brass variant ensures durability in high-salinity or high-temperature settings. Both options feature FKM seals rated for up to +130°C (on request), enhancing the device's suitability for high-temperature applications.

Model Variants and Application Flexibility

The IF1V1/A series includes multiple variants to accommodate different flow rates and system requirements. From the IF1V1/A (0.1-1 LPM) to the IF5V60/A (5-60 LPM), each model is optimized for specific industrial applications. The available thread sizes (G1/4" to G1") and pressure ratings ensure compatibility with a wide range of piping systems, allowing engineers to select the most appropriate model based on their system's flow demands and environmental conditions.

Product Summary

The IF5V60/AM9 - Visual Flow indicator - Visual Flow indicator is an industrial Flow. Selection should be based on the documented characteristics and the requirements of the intended application.
