The ELETTROTEC IF2V2E3/IM7SC Adjustable Visual and Electric Flow switch is a precision flow measurement and control device designed for high-pressure industrial applications. This instrument features a maximum flow rate of 140 l/min (H2O), operates up to 300 bar pressure, and supports 220 V AC (50 Hz) with a differential flow rate of ~45%. Its nickel-plated brass body and FKM seal ensure durability across temperatures from -10°C to +100°C, making it ideal for demanding fluid systems.
The ELETTROTEC IF3V2E6/O Adjustable Visual and Electric Flow switch is a robust, high-performance flow control and monitoring device engineered for critical industrial environments. This product combines visual indication with electric switching capabilities to provide precise flow rate regulation and real-time monitoring in high-pressure systems. With a maximum flow capacity of 140 l/min (H2O), it handles pressures up to 300 bar and operates within a wide temperature range of -10°C to +100°C, ensuring reliable performance in harsh conditions. The switch's nickel-plated brass construction and FKM seal material deliver exceptional resistance to corrosion and wear, while its SPDT contact configuration allows for flexible integration into control circuits.
The IF3V2E6/O features a maximum flow rate of 140 l/min (H2O), maximum pressure rating of 300 bar, and operates within a temperature range of -10°C to +100°C. It is designed for 220 V AC (50 Hz) with a current draw of 0.8 A (resistive) and supports switching voltages of DC 60 W or AC 60 VA. The product uses G1/4″ to G1 1/2″ threads for connection, with an FKM seal material and nickel-plated brass body construction.
This flow switch delivers reliable performance across a wide range of industrial conditions. Its adjustable visual indication allows for immediate flow rate monitoring, while the electric switching function enables precise control of fluid flow. The differential flow rate of approximately 45% ensures accurate measurement without significant signal degradation. The device operates effectively within the specified temperature range, making it suitable for both high-temperature and low-temperature environments.
The IF2V2E3/IM7SC - Adjustable Visual and Electric Flow switch is compatible with standard pipe threads ranging from G1/4″ to G1 1/2″, facilitating easy integration into existing fluid systems. Its nickel-plated brass body and FKM seal material provide excellent resistance to corrosion and wear, ensuring long-term reliability in demanding applications. The switch can be directly connected to standard electrical circuits operating at 220 V AC (50 Hz) with a maximum current of 0.8 A.
The IF2V2E3/IM7SC - Adjustable Visual and Electric Flow switch - Adjustable Visual and Electric Flow switch is an industrial Flow. Selection should be based on the documented characteristics and the requirements of the intended application.
| Feature | Specification |
|---|---|
| Max. flow rate | 140 l/min. – H 2 0 |
| Max. pressure | 300 bar |
| Max. operating voltage | 220 V – 50 Hz |
| Working temperature | -10°C + 100°C |
| Voltage intensity | 0.8 A (resistive) |
| Switching voltage in DC / AC | DC 60 W – AC 60 VA |
| Threads | G1/4″ – G1/2″ – G1″ – G1 1/2″ |
| Body material | Nickel plated brass Max. operating voltage 220 V |
| voltage | 220 V |
| Seal material | FKM |
| Housing Material | FKM contact NO |
