Product Overview

HSR-SL is a Hanyoung NUX solid state relay for electronic switching of electrical loads. The available configurations are identified by the model options, load voltage and rated load current, with model information of Low | HSR- SLD15LR □□ | HSR- SLD25LR □□ | HSR- SLD40LR □□. Current consumption: Constant current method : Less than 14 mA; Current consumption: Less than 14 mA; Rated load current: 15A | 25A | 40A; Leakage current: Less than 20 mA.

Control-signal requirements, load range, leakage current, surge capability and thermal conditions are important when selecting the relay for a switching circuit. Weight Integrated heat sink (with box): CE, UL | Approx. 226g | Approx. 266g; Weight Integrated heat sink (with box): S-MARK | Approx. 226g | Approx. 440g | Approx. 745g; Weight Heating plate removal (with box): Approx. 94g; Weight Integrated heat sink (with box): Approx. 226g | Approx. 266g.

Key Features

Key strengths of the HSR-SL come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.

Rated load current: 15A | 25A | 40A; Peak Voltage (Non-repetition): Low | 1,200 V; Leakage current: Less than 20 mA; Output ON voltage dropping: Less than 1.6 V (R.M.S); Current consumption: Constant current method : Less than 14 mA.

• Rated load current: 15A | 25A | 40A
• Peak Voltage (Non-repetition): Low | 1,200 V
• Leakage current: Less than 20 mA
• Output ON voltage dropping: Less than 1.6 V (R.M.S)
• Current consumption: Constant current method : Less than 14 mA
• Current consumption: Less than 14 mA
• return voltage (OFF Voltage): Less than 3 V
• Response Time: 1/2 Cycle + 1 ms max. (“R” type below 1 ms)
• return voltage (OFF Voltage): Less than 50 V
• Dielectric strength: 2,500 V a.c. (For 1min at 60 ㎐)

Technical Characteristics

The HSR-SL electrical performance is defined by its control signal, load voltage, rated current, switching limits and protection characteristics. These values establish the operating range for the solid state switching circuit. Output ON voltage dropping: Less than 1.6 V (R.M.S); return voltage (OFF Voltage): Less than 3 V; Response Time: 1/2 Cycle + 1 ms max. (“R” type below 1 ms); return voltage (OFF Voltage): Less than 50 V.

Additional technical characteristics include Dielectric strength: 2,500 V a.c. (For 1min at 60 ㎐); Vibration resistance: 10 - 55 Hz, Constant current method : 1.5 mm, X·Y·Z each axis direction for 2 hours; Shock resistance: 1,000 m/s², X·Y·Z each axis 3 times.

Design and Construction

The physical design of HSR-SL should be considered together with the installation environment and the available mounting or display arrangement. Storage Temperature: -30 ~ 90 ℃; Ambient Temperature: -30 ~ 80 ℃ (no condensation); Ambient Humidity: 45 ~ 85 % RH; Rated load current: 15A | 25A | 40A.

Further construction and environmental details include Peak Voltage (Non-repetition): Low | 1,200 V; Leakage current: Less than 20 mA; Output ON voltage dropping: Less than 1.6 V (R.M.S).

Integration and Operation

Integration of HSR-SL depends on matching the control signal and load circuit to the relay's rated voltage and current characteristics. Rated load current: 15A | 25A | 40A; Peak Voltage (Non-repetition): Low | 1,200 V; Leakage current: Less than 20 mA; Output ON voltage dropping: Less than 1.6 V (R.M.S).

Additional operating and interface details include Current consumption: Constant current method : Less than 14 mA; Current consumption: Less than 14 mA; return voltage (OFF Voltage): Less than 3 V. These values provide a practical reference for wiring, setup and normal operation within the selected configuration.

Selection and Use

Choose HSR-SL by confirming the exact model or configuration against the required operating conditions. The available model information is Low | HSR- SLD15LR □□ | HSR- SLD25LR □□ | HSR- SLD40LR □□. Model: Low | HSR- SLD15LR □□ | HSR- SLD25LR □□ | HSR- SLD40LR □□; High: HSR- SLD15HR □□ | HSR- SLD25HR □□ | HSR- SLD40HR □□; Model: Low | HSR- SLD15LZ □-S | HSR- SLD25LZ □-S | HSR- SLD40LZ □-S; High: HSR- SLD15HZ □-S | HSR- SLD25HZ □-S | HSR- SLD40HZ □-S.

Before installation, confirm High: 24 - 480 V a.c. 50/60 Hz; High: 170A | 250A | 370A; High: 160A | 230A | 350A. Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
