The Hollow Fiber Membrane Filter is PISCO's MFU-series filter element built around a hollow-fiber membrane. It is intended for high-purity pneumatic filtration where very fine particle removal, low contamination and clean construction are important.
The MFU series uses a stainless-steel body with a polypropylene membrane and PCT/PBT/POM support components depending on the assembly section. The official specification also identifies stainless-steel lock and guide components, FKM elastic sleeve and PBT casing.
PISCO specifies air or nitrogen as the media, a maximum operating pressure of 1.0MPa at 20℃, operating temperature 5 to 50℃, filtration accuracy 0.01μm and trapping efficiency 99.99%. Pressure resistance is 1.5MPa and differential-pressure resistance is 0.25MPa. The family includes 50 and 100L/min [ANR] classes.
Install the filter in a clean pneumatic line using the exact MFU size and tube connection. The official series is equivalent to ISO Class 6 clean-room construction and uses an oil-free configuration.
| Specification | Details |
|---|---|
| Series | MFU |
| Model range | MFU50-44, MFU50-66, MFU50-88; MFU100-66, MFU100-88, MFU100-1010 |
| Max. flow | 50 or 100L/min [ANR] |
| Media | Air, Nitrogen |
| Max. operating pressure | 1.0MPa at 20℃ |
| Operating temperature | 5 to 50℃ |
| Filtering accuracy | 0.01μm |
| Trapping efficiency | 99.99% |
| Pressure resistance | 1.5MPa |
| Differential pressure resistance | 0.25MPa |
| Membrane material | PP |
| Filter area | 4.7 / 7.5 / 12.7cm² |
| Clean-room | ISO Class 6 equivalent |
| Oil-free | Yes |
| RoHS2 | Compliant |
