Explore performance details, construction highlights, applications, and technical information in one clear overview.
Findeva Golden TurbineĀ® Vibrators GT- 4 / 6 is a Golden Turbine pneumatic vibrator for strong, high-speed vibration. The GT design uses eccentric working torque from the rotor and continuously variable speed to provide controlled centrifugal force for material-flow and process applications.
The frequency, force and air-consumption figures shown are Findeva published technical data measured under the manufacturer's specified test conditions. Actual vibration on an installed structure depends on the mounting and the mass/stiffness of the equipment.
The Golden TurbineĀ® Vibrators GT- 4 / 6 uses a powder-coated extruded aluminium alloy housing, aluminium caps, a hard-anodized aluminium rotor and an imbalance weight. The rotor is supported on two pre-lubricated enclosed ball bearings arranged in pairs.
The published operating data for GT-04 gives 14.0, 15.0 and 15.0 Ć10Ā³ minā»Ā¹ at 2, 4 and 6 bar, with centrifugal force of 135, 180 and 200 N.
The GT series is applicable up to 120Ā°C, with HT versions available on request.
| Brand | Findeva |
|---|---|
| Product family | GT Golden Turbine Vibrator |
| Model | Golden TurbineĀ® Vibrators GT- 4 / 6 |
| Findeva model reference | GT-4 |
| Rated frequency @ 2 / 4 / 6 bar | 14.0 / 15.0 / 15.0 Ć10Ā³ minā»Ā¹ |
| Centrifugal force @ 2 / 4 / 6 bar | 135 / 180 / 200 N |
| Air consumption @ 2 / 4 / 6 bar | ā / ā / ā l/min |
| Dimensions A / Width / C / D / E / F | 40 / 28 / 70 / 56 / 10.5 / 6 mm |
| Thread | G 1/8" |
| Weight | 0.17 kg |
| Maximum operating temperature | 120Ā°C; HT version on request |
Emptying bunkers, screen filters, vibrating tables, preventing adhesion in pipelines and silos, transporting fine powders and moving bulk solids.
The Golden TurbineĀ® Vibrators GT- 4 / 6 is designed for compressed-air operation within the published Findeva operating range. Its model-specific construction and pneumatic characteristics provide controlled vibration or impact for material-flow and process equipment.
| Brand | Findeva |
|---|---|
| Product family | GT Golden Turbine Vibrator |
| Model | Golden TurbineĀ® Vibrators GT- 4 / 6 |
| Findeva model reference | GT-4 |
| Rated frequency @ 2 / 4 / 6 bar | 14.0 / 15.0 / 15.0 Ć10Ā³ minā»Ā¹ |
| Centrifugal force @ 2 / 4 / 6 bar | 135 / 180 / 200 N |
| Air consumption @ 2 / 4 / 6 bar | ā / ā / ā l/min |
| Dimensions A / Width / C / D / E / F | 40 / 28 / 70 / 56 / 10.5 / 6 mm |
| Thread | G 1/8" |
| Weight | 0.17 kg |
| Maximum operating temperature | 120Ā°C; HT version on request |
