Explore performance details, construction highlights, applications, and technical information in one clear overview.
FRN0072E2S-4A is a Fuji Electric FRENIC-Ace (E2) high-performance inverter in the three-phase 400 V class. The model is specified for 30 kW HND / 25 kW HHD duty ratings with 45 A HND / 39 A HHD rated-current values and provides advanced motor control, communication and functional-safety features.
FRENIC-Ace (E2) provides sensorless Dynamic Torque Vector Control and model-dependent vector-control functions.
Two onboard RS-485 communication ports and CANopen compatibility support automation-system integration.
Customizable logic provides up to 200 programming steps.
STO functional safety is provided as a standard function.
| Brand | Fuji Electric |
|---|---|
| Series | FRENIC-Ace (E2) |
| Model | FRN0072E2S-4A |
| Input voltage class | Three-phase 400 V |
| Applicable motor rating | 30 kW HND / 25 kW HHD |
| Rated current | 45 A HND / 39 A HHD |
| Control | Sensorless Dynamic Torque Vector Control |
| Communication | 2-channel onboard RS-485; CANopen compatibility |
| Customizable logic | Up to 200 steps |
| Safety | STO standard |
Industrial machinery, conveyors, pumps, fans, compressors, machine tools and automation systems requiring variable-speed AC motor control.
Fuji Electric develops AC drives and automation products for industrial motor control, motion control and electrical equipment. The product information presented for FRN0072E2S-4A focuses on the published characteristics of its specific product family and model.
| Brand | Fuji Electric |
|---|---|
| Series | FRENIC-Ace (E2) |
| Model | FRN0072E2S-4A |
| Input voltage class | Three-phase 400 V |
| Applicable motor rating | 30 kW HND / 25 kW HHD |
| Rated current | 45 A HND / 39 A HHD |
| Control | Sensorless Dynamic Torque Vector Control |
| Communication | 2-channel onboard RS-485; CANopen compatibility |
| Customizable logic | Up to 200 steps |
| Safety | STO standard |
