Explore performance details, construction highlights, applications, and technical information in one clear overview.
Findeva FP-35-L is a pneumatic piston vibrator for linear vibration in feeders, chutes and bulk-material equipment. The FP design provides continuously adjustable vibration frequency and force through compressed-air control.
The FP-35-L uses the FP-series piston-vibrator design with a hard-anodized aluminium housing and spring-driven piston. The construction is intended for controlled linear vibration and can be installed in different operating positions.
At 2, 4 and 6 bar, the model provides 2.4, 3.1 and 3.6 ×10³ vibrations per minute and 282, 680 and 1066 N force.
Published air consumption is 38, 89 and 135 l/min at 2, 4 and 6 bar. The model weighs 1.38 kg and uses G 1/4" / G 1/4" pneumatic connections.
| Brand | Findeva |
|---|---|
| Product family | FP Piston Vibrator |
| Model | FP-35-L |
| Rated frequency @ 2 / 4 / 6 bar | 2.4 / 3.1 / 3.6 ×10³ min⁻¹ |
| Force @ 2 / 4 / 6 bar | 282 / 680 / 1066 N |
| Air consumption @ 2 / 4 / 6 bar | 38 / 89 / 135 l/min |
| Length A | 136 mm |
| Width / wrench size | 65 mm / M12 |
| Connections | G 1/4" / G 1/4" |
| Weight | 1.38 kg |
| Maximum operating temperature | 150°C |
Driving conveyor and discharge chutes, loosening or compacting bulk solids, activating mechanical processes and filling facilities.
The FP-35-L is designed for compressed-air operation within the published Findeva operating range. Its model-specific construction and pneumatic characteristics provide controlled vibration or impact for material-flow and process equipment.
| Brand | Findeva |
|---|---|
| Product family | FP Piston Vibrator |
| Model | FP-35-L |
| Rated frequency @ 2 / 4 / 6 bar | 2.4 / 3.1 / 3.6 ×10³ min⁻¹ |
| Force @ 2 / 4 / 6 bar | 282 / 680 / 1066 N |
| Air consumption @ 2 / 4 / 6 bar | 38 / 89 / 135 l/min |
| Length A | 136 mm |
| Width / wrench size | 65 mm / M12 |
| Connections | G 1/4" / G 1/4" |
| Weight | 1.38 kg |
| Maximum operating temperature | 150°C |
