Explore performance details, construction highlights, applications, and technical information in one clear overview.
Findeva FP-25-L is a pneumatic piston vibrator for linear vibration in feeders, chutes and bulk-material equipment. The FP design provides continuously adjustable vibration frequency and force through compressed-air control.
The FP-25-L uses the FP-series piston-vibrator design with a hard-anodized aluminium housing and spring-driven piston. The construction is intended for controlled linear vibration and can be installed in different operating positions.
At 2, 4 and 6 bar, the model provides 2.4, 3.1 and 3.7 ×10³ vibrations per minute and 186, 392 and 594 N force.
Published air consumption is 18, 62 and 93 l/min at 2, 4 and 6 bar. The model weighs 0.82 kg and uses G 1/8" / G 1/4" pneumatic connections.
| Brand | Findeva |
|---|---|
| Product family | FP Piston Vibrator |
| Model | FP-25-L |
| Rated frequency @ 2 / 4 / 6 bar | 2.4 / 3.1 / 3.7 ×10³ min⁻¹ |
| Force @ 2 / 4 / 6 bar | 186 / 392 / 594 N |
| Air consumption @ 2 / 4 / 6 bar | 18 / 62 / 93 l/min |
| Length A | 136 mm |
| Width / wrench size | 50 mm / M12 |
| Connections | G 1/8" / G 1/4" |
| Weight | 0.82 kg |
| Maximum operating temperature | 150°C |
Driving conveyor and discharge chutes, loosening or compacting bulk solids, activating mechanical processes and filling facilities.
The FP-25-L is designed for compressed-air operation within the published Findeva operating range. Its model-specific construction and pneumatic characteristics provide controlled vibration or impact for material-flow and process equipment.
| Brand | Findeva |
|---|---|
| Product family | FP Piston Vibrator |
| Model | FP-25-L |
| Rated frequency @ 2 / 4 / 6 bar | 2.4 / 3.1 / 3.7 ×10³ min⁻¹ |
| Force @ 2 / 4 / 6 bar | 186 / 392 / 594 N |
| Air consumption @ 2 / 4 / 6 bar | 18 / 62 / 93 l/min |
| Length A | 136 mm |
| Width / wrench size | 50 mm / M12 |
| Connections | G 1/8" / G 1/4" |
| Weight | 0.82 kg |
| Maximum operating temperature | 150°C |
