Explore performance details, construction highlights, applications, and technical information in one clear overview.
Findeva FAL-35 is a pneumatic piston vibrator for linear vibration with continuously adjustable frequency and force. The FAL range uses lubrication-free operation and is suited to food, pharmaceutical and bulk-material handling applications.
The FAL-35 generates vibration with a freely oscillating, self-reversing piston. The design provides linear vibration and allows frequency and amplitude to be adjusted continuously through the compressed-air supply.
At 2, 4 and 6 bar, the model produces 1.24, 1.55 and 2.01 ×10³ vibrations per minute, with force of 205, 340 and 655 N.
The published model data gives a piston stroke of 37.0 mm and a weight of 2.35 kg.
| Brand | Findeva |
|---|---|
| Product family | FAL / VTL Piston Vibrator |
| Model | FAL-35 |
| Rated frequency @ 2 / 4 / 6 bar | 1.24 / 1.55 / 2.01 ×10³ min⁻¹ |
| Force @ 2 / 4 / 6 bar | 205 / 340 / 655 N |
| Air consumption @ 2 / 4 / 6 bar | 75 / 220 / 350 l/min |
| Dimension A | 140 mm |
| Diameter / width | 77 mm |
| Mounting / connections | M16 / G 1/4" / G 1/4" |
| Weight | 2.35 kg |
| Piston stroke | 37.0 mm |
| Maximum temperature | FAL up to 85°C; VTL-165 up to 150°C |
Food and pharmaceutical equipment, conveyor and discharge chutes, loosening or compacting bulk solids, activating mechanical processes and filling facilities.
The FAL-35 is designed for compressed-air operation within the published Findeva operating range. Its model-specific construction and pneumatic characteristics provide controlled vibration or impact for material-flow and process equipment.
| Brand | Findeva |
|---|---|
| Product family | FAL / VTL Piston Vibrator |
| Model | FAL-35 |
| Rated frequency @ 2 / 4 / 6 bar | 1.24 / 1.55 / 2.01 ×10³ min⁻¹ |
| Force @ 2 / 4 / 6 bar | 205 / 340 / 655 N |
| Air consumption @ 2 / 4 / 6 bar | 75 / 220 / 350 l/min |
| Dimension A | 140 mm |
| Diameter / width | 77 mm |
| Mounting / connections | M16 / G 1/4" / G 1/4" |
| Weight | 2.35 kg |
| Piston stroke | 37.0 mm |
| Maximum temperature | FAL up to 85°C; VTL-165 up to 150°C |
