IFM EVT172 is a 0.3 m M8 connection cable with LED indication, designed for hygienic and wet food-industry applications. It provides reliable signal status indication, gold-plated contacts and high IP protection.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Compact LED Connection Cable
EVT172 combines M8 connection technology with visible LED indicators for convenient monitoring of operating and switching status.
0.3 m Cable Length
The short orange PVC cable is suitable for compact sensor installations where minimal cable routing is required.
Clear Status Indication
The green power LED and yellow switching-status LED make operating conditions easy to identify, even where visual monitoring is important.
Hygienic Design
The cable is suitable for hygienic and wet food-industry areas and is manufactured without silicone.
Reliable Mechanical Performance
Stainless-steel locking components, IP65/IP67/IP68/IP69K protection and drag-chain suitability provide dependable performance in demanding automation systems. IFM lists EVT172–EVT175 as the LED variants in this M8 jumper series.
Compact 0.3 m cable
Integrated LED status indication
Gold-plated contacts
High IP protection
Silicone-free construction
Suitable for drag-chain applications
Food-processing machinery
Packaging equipment
Sensor monitoring
Hygienic automation
Industrial control systems
Machine-building applications
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | EVT172 |
| Product Type | Connection Cable |
| Order Code | VDOAF032VAS003E03STAF030VAS |
| Cable Length | 0.3 m |
| Connector | M8 |
| Electrical Design | DC PNP |
| Operating Voltage | 10–36 V DC |
| Current Rating | 3 A |
| Cable Material | PVC |
| Cable Colour | Orange |
| Cable Diameter | 4.9 mm |
| Conductor | 3 x 0.34 mm² |
| Contacts | Gold-plated |
| Status LED | Yellow |
| Power LED | Green |
| Locking | Stainless steel 316L |
| Sealing | EPDM |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to 80°C |
| Drag Chain Suitable | Yes |
| Bending Cycles | >1 million |
| Silicone Free | Yes |
