IFM EVT002 is a 10 m M12 connecting cable with a straight socket, designed for hygienic and wet food-industry environments. It features four conductors, gold-plated contacts, stainless-steel locking and high IP protection.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Reliable M12 Connection
IFM EVT002 provides a dependable connection between sensors and automation components. Its straight M12 socket with A coding ensures secure and reliable industrial connectivity.
10 m Cable Length
The 10 m orange PVC cable provides extended installation flexibility for machines and production systems where connected components are positioned farther apart.
Hygienic Industrial Design
The cable is designed for hygienic and wet areas in the food industry. Its silicone-free construction supports applications where cleanliness and material compatibility are important.
Durable Connection Construction
Gold-plated contacts help maintain reliable electrical conductivity, while the stainless-steel locking mechanism provides secure mechanical coupling.
High Environmental Protection
IP65, IP67, IP68 and IP69K protection makes EVT002 suitable for wet, washdown and demanding industrial environments. The cable is also suitable for drag-chain applications.
10 m extended connection length
Straight M12 socket
Gold-plated contacts
High IP protection
Stainless-steel locking mechanism
Suitable for drag-chain applications
Food-processing machinery
Packaging equipment
Industrial automation
Sensor connections
Hygienic production lines
Wet-area machinery
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | EVT002 |
| Product Type | Connecting Cable with Socket |
| Order Code | ADOGH040VAS0010E04 |
| Cable Length | 10 m |
| Connector | M12 |
| Connector Design | Straight |
| Coding | A |
| Conductors | 4 x 0.34 mm² |
| Cable Material | PVC |
| Cable Colour | Orange |
| Cable Diameter | 4.9 mm |
| Contacts | 4, gold-plated |
| Locking Material | Stainless steel 316L / 1.4404 |
| Sealing | EPDM |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to 100°C |
| Drag Chain Suitable | Yes |
| Silicone Free | Yes |
| Tightening Torque | 0.6–1.5 Nm |
