IFM EVM024 is a 2 m connecting cable with an angled A-coded M8 socket designed for mobile machines and particularly harsh industrial environments. It offers reliable connectivity, high IP protection and resistance to oils and coolants.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Angled M8 Socket
The angled M8 socket supports convenient cable routing in restricted installation spaces.
2 m Cable Length
The 2 m cable is suitable for compact sensor and automation installations.
Three-Core Design
Three 0.25 mm² conductors provide reliable electrical transmission.
Durable PUR Cable
The black PUR cable is designed for demanding industrial and mobile applications.
Gold-Plated Contacts
Gold-plated contacts support reliable electrical connectivity.
High IP Protection
IP65, IP67, IP68 and IP69K protection provides resistance to water and harsh conditions.
Provides practical 2 m connectivity
Offers convenient angled M8 connection
Provides stable electrical transmission
Resists vibration and shock
Resists oils and coolants
Suitable for drag-chain applications
Mobile machines
Industrial automation systems
M8 sensor installations
Heavy-duty machinery
Oil and coolant exposed applications
Harsh industrial environments
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | EVM024 |
| Product Type | Connecting Cable with Socket |
| Order Code | ADOAF030VAS0002H03 |
| Cable Length | 2 m |
| Connector | M8 Socket |
| Connector Design | Angled |
| Coding | A-coded |
| Conductors | 3 x 0.25 mm² |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | 3.7 mm |
| Contacts | Gold-plated |
| Locking Material | Stainless Steel 316L / 1.4404 |
| Sealing | FKM |
| Current Rating | 3 A |
| Operating Voltage | 50 V AC / 60 V DC |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to 90°C |
| Drag Chain Suitable | Yes |
| Silicone Free | Yes |
| Halogen Free | Yes |
