IFM EVM022 is a 10 m connecting cable with a straight A-coded M8 socket for reliable sensor and automation connections. It is designed for mobile machinery and harsh industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Straight M8 Socket
The straight M8 socket provides dependable connection with compatible industrial sensors.
10 m Cable Length
The 10 m cable provides extended installation flexibility.
Three-Core Construction
Three 0.25 mm² conductors support reliable signal transmission.
PUR Cable Material
The black PUR cable provides durability in demanding environments.
Gold-Plated Contacts
Gold-plated contacts support stable and reliable electrical connections.
High IP Protection
IP65, IP67, IP68 and IP69K protection helps protect against harsh environmental conditions.
Provides extended 10 m connectivity
Offers reliable straight M8 connection
Supports stable signal transmission
Provides vibration and shock resistance
Suitable for mobile applications
Supports drag-chain usage
Mobile machinery
Industrial automation systems
Sensor installations
M8 connection applications
Heavy-duty machinery
Harsh industrial environments
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | EVM022 |
| Product Type | Connecting Cable with Socket |
| Order Code | ADOGF030VAS0010H03 |
| Cable Length | 10 m |
| Connector | M8 Socket |
| Connector Design | Straight |
| Coding | A-coded |
| Conductors | 3 x 0.25 mm² |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | 3.7 mm |
| Contacts | Gold-plated |
| Sealing | FKM |
| Current Rating | 3 A |
| Operating Voltage | 50 V AC / 60 V DC |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to 90°C |
| Drag Chain Suitable | Yes |
| Silicone Free | Yes |
| Halogen Free | Yes |
