IFM EVF697 is a 19 m Industrial Ethernet connection cable with two angled D-coded M12 connectors. It is designed for CAT5/CAT5e and PROFINET applications, offering shielded data transmission, high IP protection and reliable performance in hygienic and wet environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Industrial Ethernet Connection
EVF697 features two angled D-coded M12 connectors designed for reliable Industrial Ethernet communication.
19 m Cable Length
The 19 m grey MPPE cable provides extended connectivity for large machines and automation installations.
PROFINET Type C Design
The cable uses PROFINET Type C construction with four 0.34 mm² conductors and supports CAT5/CAT5e communication up to 100 Mbit/s.
Shielded Cable Construction
The screened cable helps improve electromagnetic compatibility and supports stable data transmission in industrial environments.
Hygienic Construction
The silicone-free and halogen-free cable is suitable for hygienic and wet areas, including food-processing environments.
High Protection
Gold-plated contacts, stainless-steel locking components and IP65/IP67/IP68/IP69K protection support reliable operation under demanding conditions.
Provides extended 19 m Industrial Ethernet connectivity.
Supports CAT5/CAT5e and PROFINET communication.
Provides shielded data transmission for improved EMC performance.
Offers reliable D-coded M12 connections.
Suitable for hygienic and wet environments.
Suitable for drag-chain applications.
Industrial Ethernet networks
PROFINET automation systems
Food-processing machinery
Packaging equipment
Industrial communication systems
Hygienic automation installations
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | EVF697 |
| Product Type | Ethernet Connection Cable |
| Order Code | VSTAN040VAS0019R04STAN040VAS |
| Cable Length | 19 m |
| Connector | 2 x M12 |
| Connector Design | Angled |
| Coding | D-coded |
| Application | Industrial Ethernet / CAT5/CAT5e |
| Data Rate | 100 Mbit/s |
| Cable Type | PROFINET Type C |
| Cable Material | MPPE |
| Cable Colour | Grey |
| Cable Diameter | 6.5 mm |
| Conductors | 4 x 0.34 mm² |
| Contacts | Gold-plated |
| Shielding | Screened |
| Locking Material | Stainless Steel 316L / 1.4404 |
| Operating Voltage | 30 V AC / 60 V DC |
| Current Rating | 4 A |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to 100°C |
| Drag Chain Suitable | Yes |
| Silicone Free | Yes |
| Halogen Free | Yes |
