IFM EVF690 is a 16 m Ethernet connection cable designed for Industrial Ethernet and PROFINET applications. It features two angled D-coded M12 connectors, shielded PROFINET Type C cable and high IP protection for reliable communication in demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
D-Coded M12 Connection
EVF690 features two angled D-coded M12 connectors for secure Industrial Ethernet connections between compatible automation devices.
16 m Cable Length
The 16 m cable provides extended reach for industrial installations and automation systems where communication devices are positioned farther apart.
PROFINET Type C Cable
The cable uses PROFINET Type C construction with four 0.34 mm² conductors and supports CAT5/CAT5e Industrial Ethernet communication up to 100 Mbit/s.
Shielded Construction
The screened cable supports electromagnetic compatibility and helps maintain stable data transmission in industrial environments.
Drag Chain Suitable
EVF690 is designed for dynamic applications and can be used in drag-chain systems with suitable bending and travel conditions.
High Protection
IP65, IP67, IP68 and IP69K protection helps protect the cable against water, moisture and cleaning conditions.
EVF690 provides extended 16 m Ethernet connectivity with shielded PROFINET Type C construction, D-coded M12 connectors and gold-plated contacts. Its drag-chain suitability and high IP protection make it suitable for demanding automation systems.
EVF690 is suitable for PROFINET networks, Industrial Ethernet systems, automated production machinery, packaging equipment, food-processing applications, machine communication and dynamic cable-chain installations.
| Specification | Details |
|---|---|
| Brand | IFM |
| Model | EVF690 |
| Product Type | Ethernet Connection Cable |
| Order Code | VSTAN040VAS0016R04STAN040VAS |
| Cable Length | 16 m |
| Connector | 2 x M12 |
| Connector Design | Angled |
| Coding | D-coded |
| Application | Industrial Ethernet / CAT5/CAT5e |
| Data Rate | 100 Mbit/s |
| Cable Type | PROFINET Type C |
| Conductors | 4 x 0.34 mm² |
| Cable Material | MPPE |
| Cable Colour | Grey |
| Cable Diameter | 6.5 mm |
| Contacts | Gold-plated |
| Shielding | Screened |
| Locking Material | Stainless Steel 316L / 1.4404 |
| Operating Voltage | 30 V AC / 60 V DC |
| Current Rating | 4 A |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to 100°C |
| Drag Chain Suitable | Yes |
| Silicone Free | Yes |
| Halogen Free | Yes |
