IFM EVF095 is a 20 m M12 connecting cable with angled socket for reliable sensor and automation connections. Its halogen-free construction, gold-plated contacts, EPDM sealing and IP65/IP67/IP68/IP69K protection support demanding hygienic and wet-area applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM EVF095 is a long-length connecting cable with M12 socket designed for industrial automation and sensor applications. Its 20 m cable length enables flexible installation where sensors and control equipment are positioned at greater distances.
The angled M12 A-coded socket provides convenient connection in confined installation spaces. Gold-plated contacts help provide stable electrical connectivity, while the stainless-steel 316L locking nut provides mechanical durability.
The cable uses halogen-free MPPE material and EPDM sealing. Its robust construction supports operation in hygienic and wet areas and is suitable for food-industry machinery.
The EVF095 is also suitable for drag-chain applications, supporting repeated movement with a minimum bending radius of 10 times the cable diameter.
20 m Extended Reach
Suitable for installations requiring longer sensor connections.
Angled M12 Socket
Provides easier routing in restricted spaces.
Reliable Electrical Contact
Gold-plated contacts support dependable signal transmission.
Strong Environmental Protection
Designed for wet and hygienic environments.
Dynamic Application Support
Suitable for drag-chain installations.
Industrial sensors
Food-processing machinery
Packaging systems
Automation equipment
Conveyor systems
Machine control
Wet production environments
| Specification | Details |
|---|---|
| Product Model | EVF095 |
| Order Code | ADOAH040VAS0020P04 |
| Product Type | Connecting Cable with Socket |
| Cable Length | 20 m |
| Connector | M12 socket |
| Connector Design | Angled |
| Coding | A-coded |
| Contacts | 4 |
| Cable Cross-section | 4 x 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Material | MPPE |
| Sheath | Grey, halogen-free |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Protection Class | II |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Sealing | EPDM |
| Locking Nut | Stainless steel 316L |
| Contacts | Gold-plated |
| Drag Chain Suitable | Yes |
| Application | Hygienic and wet areas |
