IFM EVC931 Ethernet connection cable features a 1 m shielded PUR PROFINET cable with an angled M12 D-coded connector and straight RJ45 connector. It provides reliable Industrial Ethernet connectivity for industrial automation systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM EVC931 provides a 1 m connection length for Industrial Ethernet applications where compact and reliable networking is required.
The cable combines an angled M12 D-coded connector with a straight RJ45 connector. This configuration provides flexibility when routing the cable around machinery and panels.
The green cable uses a shielded, halogen-free PUR sheath with PROFINET Type C construction and 4 × 0.34 mm² conductors.
The EVC931 is suitable for cable-chain applications. Available technical information specifies IP65/IP67 protection at the M12 side, while the M12/RJ45 interface has its own connector-specific protection rating. It is also specified for industrial Ethernet, CAT5/CAT5e and 100 Mbit/s applications.
1 m Cable Length: Suitable for compact machine connections.
Angled M12 Connector: Supports flexible cable routing.
Straight RJ45 Connector: Provides convenient Ethernet connectivity.
Shielded PUR Cable: Helps minimise electromagnetic interference.
Cable-Chain Suitable: Supports dynamic industrial applications.
Industrial Ethernet
PROFINET networks
Factory automation
Machine tools
Control cabinets
Industrial switches
Production machinery
Dynamic automation systems
| Specification | Details |
|---|---|
| Product Code | EVC931 |
| Article Number | VSTAN040MSS0001K04STGP040--S |
| Product Type | Ethernet Connection Cable |
| Cable Length | 1 m |
| Cable Material | PUR |
| Cable Colour | Green |
| Cable Diameter | 6.5 mm |
| Cable Type | Shielded |
| Halogen-Free | Yes |
| Standard | PROFINET Type C |
| Conductors | 4 × 0.34 mm² |
| Connector 1 | M12, angled |
| M12 Coding | D |
| M12 Contacts | Gold-plated |
| M12 Housing | TPU, black |
| Connector 2 | RJ45, straight |
| RJ45 Contacts | Gold-plated |
| RJ45 Housing | PC |
| Operating Voltage | 30 V AC / 60 V DC |
| Maximum Current | 1.5 A |
| Protection | IP65 / IP67; M12/RJ45 interface IP20 |
| Operating Temperature | -25 to +90 °C |
| Cable Chain Suitability | Yes |
| Cable Chain Bending Radius | Min. 10 × cable diameter |
| Max. Travel Speed | 3.3 m/s |
| Bending Cycles | > 3 million |
| Application | Industrial Ethernet |
| Transmission | CAT5/CAT5e, 100 Mbit/s |
| Pack Quantity | 1 pc |
