IFM EVC906 connection cable features a 2 m shielded PUR cable with straight M12 D-coded connectors. Designed for Industrial Ethernet and CAT5/CAT5e communication, it offers reliable connectivity for industrial automation systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM EVC906 provides a practical 2 m connection for Industrial Ethernet devices used in factory automation and machine applications.
The straight M12 D-coded connectors provide secure connection and feature gold-plated contacts for reliable electrical performance.
The green PUR cable is shielded and halogen-free. Its robust construction makes it suitable for industrial installations and dynamic cable routing.
The EVC906 offers IP65/IP67 protection and drag-chain suitability. IFM specifies CAT5/CAT5e and 100 Mbit/s Industrial Ethernet applications.
2 m Reach: Provides flexible connection between nearby automation components.
Shielded Cable: Helps maintain communication reliability.
M12 D Coding: Suitable for Industrial Ethernet connections.
High Protection: IP65/IP67 protection supports industrial environments.
Dynamic Use: Suitable for drag-chain applications.
Industrial Ethernet
Factory automation
Machine tools
Production machinery
Industrial networking
Control systems
Automation equipment
Machine communication
| Specification | Details |
|---|---|
| Product Code | EVC906 |
| Article Number | VSTGN040MSS0002K04STGN040MSS |
| Product Type | Connection Cable |
| Cable Length | 2 m |
| Cable Material | PUR |
| Cable Colour | Green |
| Cable Diameter | 6.5 mm |
| Cable Type | Shielded / Halogen-free |
| Standard | PROFINET Type C |
| Conductors | 4 × 0.34 mm² |
| Connector 1 | M12, straight |
| Connector 2 | M12, straight |
| Coding | D |
| Contacts | 4, gold-plated |
| Operating Voltage | 30 V AC / 60 V DC |
| Maximum Current | 4 A |
| Protection | IP65 / IP67 |
| Ambient Temperature | -25 to +90 °C |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >3 million |
| Application | Industrial Ethernet |
| Transmission | CAT5/CAT5e, 100 Mbit/s |
| Pack Quantity | 1 pc |
