IFM EVC901 connecting cable with plug provides a 20 m shielded PUR cable with an angled M12 D-coded connector. Designed for Industrial Ethernet and CAT5/CAT5e applications, it supports reliable communication in demanding factory environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM EVC901 is designed for Industrial Ethernet applications requiring a long cable connection between automation and network devices.
The 20 m cable length provides extended installation flexibility for larger machines, production lines and distributed industrial equipment.
The angled M12 connector supports convenient cable routing while its D coding is designed for Industrial Ethernet applications.
The shielded, halogen-free PUR cable includes gold-plated contacts and a secure nickel-plated brass locking mechanism. IFM specifies CAT5/CAT5e, 100 Mbit/s, IP65/IP67 protection and drag-chain suitability.
Extended 20 m Reach: Suitable for larger industrial installations.
Angled M12 Connector: Helps improve cable routing in restricted spaces.
Industrial Ethernet Ready: Supports CAT5/CAT5e and 100 Mbit/s applications.
Reliable Signal Transmission: Shielded construction helps reduce interference.
Dynamic Application Support: Suitable for drag-chain installations.
Industrial Ethernet
Factory automation
Machine tools
Production lines
Industrial machinery
Automation networks
Machine control
Control systems
| Specification | Details |
|---|---|
| Product Code | EVC901 |
| Product Type | Connecting Cable with Plug |
| Article Number | ASTAN040MSS0020K04 |
| Cable Length | 20 m |
| Cable Material | PUR |
| Cable Colour | Green |
| Cable Diameter | 6.5 mm |
| Cable Type | Shielded / Halogen-free |
| Cable Standard | PROFINET Type C |
| Conductors | 4 × 0.34 mm² |
| Connector | M12, angled |
| Coding | D |
| Contacts | Gold-plated |
| Housing | TPU, black |
| Locking | Brass, nickel-plated |
| Operating Voltage | 30 V AC / 60 V DC |
| Maximum Current | 4 A |
| Protection | IP65 / IP67 |
| Ambient Temperature | -25 to +90 °C |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >3 million |
| Travel Speed | Max. 3.3 m/s |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
