IFM EVC830 connection cable with 6 m PUR cable and M8 straight connector is designed for reliable industrial signal transmission. It offers high protection, durable construction, gold-plated contacts and reliable performance in demanding automation environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM EVC830 connection cable provides a dependable connection between industrial sensors, actuators and automation components. Its compact M8 connector design supports reliable installation in space-constrained control and machine environments.
The cable uses a 6 m PUR, halogen-free cable with a 3 x 0.34 mm² conductor configuration. PUR construction provides good resistance for demanding industrial applications and helps support long-term cable performance.
The cable features a straight M8 connector with gold-plated contacts and a nickel-plated brass locking nut. This configuration supports stable electrical connection and secure mechanical fastening.
The EVC830 is designed with IP65, IP67, IP68 and IP69K protection, making it suitable for applications where exposure to dust, moisture, cleaning processes and industrial contaminants can occur.
Reliable Signal Transmission: Gold-plated contacts support dependable electrical connectivity.
High Environmental Protection: Multiple IP protection ratings help protect the connection against dust and moisture.
Flexible Installation: The 6 m cable provides additional installation flexibility.
Durable PUR Cable: PUR construction supports use in demanding industrial environments.
Maintenance-Friendly Design: Secure locking construction helps maintain a stable connection.
Industrial automation systems
Sensor and actuator connections
Machine control systems
Factory automation equipment
Production and assembly machinery
Machine-tool applications
Control and monitoring systems
| Specification | Details |
|---|---|
| Product Code | EVC830 |
| Product Type | Connection Cable |
| Part Number | VDOGH030MSS0006H03STGF030MSS |
| Cable Length | 6 m |
| Cable Material | PUR |
| Cable Type | Halogen-free |
| Connector | M8, straight |
| Coding | A |
| Conductors | 3 x 0.34 mm² |
| Contact Material | Gold-plated |
| Locking Nut | Brass, nickel-plated |
| Housing Material | TPU / Urethane |
| Sealing | FKM |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Operating Voltage | <50 V AC / <60 V DC |
| Ambient Temperature | -25 to +90 °C |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| Pack Quantity | 1 pc |
