The IFM EVC827 VDOAH030MSS0008H03STGH030MSS is a connection cable designed for reliable electrical connectivity between compatible industrial automation devices. With an 8 m PUR cable, M12 connection technology and gold-plated contacts, it provides a dependable connection solution for sensors, actuators and field devices used in machinery and factory automation systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The IFM EVC827 VDOAH030MSS0008H03STGH030MSS is a connection cable designed to provide reliable electrical connectivity between compatible industrial automation components.
Connection Cable
The EVC827 provides a practical connection solution between compatible sensors, actuators and other industrial field devices. Its M12 connection technology supports convenient installation and organized wiring within industrial automation systems.
8 m Cable Length
With an 8 m cable length, the EVC827 is suitable for installations where extended connection reach is required between field devices and control or automation equipment. The PUR cable construction provides a durable and flexible solution for industrial applications.
M12 Connection
The EVC827 features a straight M12 plug and an angled M12 socket, both with A coding and gold-plated contacts. The connectors use TPU moulded bodies, brass nickel-plated locking components and FKM sealing on the socket for dependable industrial connectivity.
Industrial Automation Applications
The EVC827 can be used with compatible industrial sensors, proximity sensors, actuators, machine-control equipment, conveyor systems and factory automation components where the cable configuration is suitable.
Application Performance
The EVC827 is designed for demanding industrial applications and provides resistance to oils and coolants, vibration and shock resistance, and reliable sealing. It has IP65, IP67, IP68 and IP69K protection ratings and is suitable for drag-chain applications. The cable supports more than 5 million bending cycles and a maximum travel speed of 3.3 m/s under specified conditions.
Industrial Automation Integration
The cable is suitable for machinery, control panels, production equipment, factory automation systems and other industrial installations requiring reliable field-device connectivity.
Key Features
IFM EVC827 connection cable
Model: VDOAH030MSS0008H03STGH030MSS
8 m cable length
PUR cable construction
Halogen-free cable
Silicone-free cable
M12 connection technology
A-coded connectors
Straight M12 plug
Angled M12 socket
Gold-plated contacts
TPU moulded connector bodies
Brass, nickel-plated locking components
FKM sealing material
Resistant to oils and coolants
Vibration and shock resistant
Suitable for drag-chain applications
Minimum bending radius of 10 × cable diameter
Maximum travel speed of 3.3 m/s under specified conditions
More than 5 million bending cycles
Torsional strain of ±180°/m
Protection ratings up to IP69K
Suitable for industrial automation
Suitable for sensors and actuators
Suitable for machinery and factory automation
| Parameter | Specification |
|---|---|
| Product Code | EVC827 |
| Manufacturer | IFM electronic |
| Product Type | Connection Cable |
| Model / Part Number | VDOAH030MSS0008H03STGH030MSS |
| Cable Length | 8 m |
| Cable Material | PUR |
| Cable Type | Halogen-free, silicone-free, black |
| Cable Diameter | Ø 4.3 mm |
| Core Specification | 3 × 0.34 mm² |
| Connection Type | M12 connection |
| Plug | 1 × M12, straight |
| Socket | 1 × M12, angled |
| Coding | A-coded |
| Contacts | Gold-plated |
| Connector Body | TPU (urethane), orange |
| Locking Nut | Brass, nickel-plated |
| Sealing Material | FKM |
| Tightening Torque | 0.6–1.5 Nm |
| Operating Voltage | < 250 V AC / < 300 V DC |
| Protection Class | II |
| Maximum Total Current Load | 4 A |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 °C to +90 °C |
| Ambient Temperature, Moving | -25 °C to +90 °C |
| Storage Temperature | -25 °C to +55 °C |
| Drag-Chain Suitability | Yes |
| Minimum Bending Radius | 10 × cable diameter |
| Maximum Travel Speed | 3.3 m/s |
| Bending Cycles | > 5 million |
| Torsional Strain | ±180°/m |
| Weight | 265.4 g |
| Application | Industrial automation |
| Typical Use | Sensors, actuators, machinery and factory automation |
