The IFM EVC708 is a 10 m connecting cable with a straight M12 socket designed for industrial field-module and automation applications.
Its 4 × 1.00 mm² PUR cable provides a large conductor cross-section for reduced voltage drop.
The cable is resistant to oils and coolants and uses gold-plated contacts for dependable electrical connectivity.
High IP protection and drag-chain suitability provide reliable performance in demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC708 provides an extended 10 m connection solution for industrial automation and field-module applications. It is suitable for installations requiring longer cable routing.
The cable uses a straight A-coded M12 socket with four gold-plated contacts. Its 4 × 1.00 mm² PUR cable provides reliable electrical and power transmission.
The cable is halogen-free and resistant to oils and coolants. TPU housing, nickel-plated brass locking components and FKM sealing provide robust protection.
The EVC708 supports high-reliability industrial connections and is suitable for drag-chain applications. Its IP65, IP67, IP68 and IP69K protection helps protect against demanding environmental conditions.
10 m cable length
Straight M12 socket
A-coded connector
4 contacts
4 × 1.00 mm² PUR cable
6.2 mm cable diameter
Gold-plated contacts
Halogen-free
Silicone-free
TPU housing
FKM sealing
Nickel-plated brass nut
Oil and coolant resistant
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Factory automation
Field modules
Power supply connections
Machine control systems
Industrial electrical equipment
Production machinery
Machine tools
Automation equipment
Long-distance connections
| Specification | Details |
|---|---|
| Product Code | EVC708 |
| Model | ADOGH040MSP0010H04 |
| Product Type | Connecting Cable with Socket |
| Cable Length | 10 m |
| Connector | M12 Straight Socket |
| Coding | A-coded |
| Contacts | 4 |
| Cable Material | PUR |
| Cable Cross Section | 4 × 1.00 mm² |
| Cable Diameter | 6.2 mm |
| Cable Colour | Black |
| Electrical Design | AC/DC |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Contact Material | Gold-plated |
| Housing Material | TPU |
| Nut Material | Nickel-plated Brass |
| Sealing Material | FKM |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to +90 °C |
| Drag Chain Suitable | Yes |
| Minimum Bending Radius | 10 × Cable Diameter |
| Maximum Travel Speed | 3.3 m/s |
| Bending Cycles | > 5 million |
| Weight | Approx. 668 g |
