The IFM EVC699 is a 1.5 m connection cable designed for reliable M8 connections in industrial automation systems.
It features straight M8 connectors with gold-plated contacts for dependable electrical transmission.
The 3 × 0.25 mm² PUR cable provides flexibility and resistance to demanding industrial conditions.
Its high IP protection and drag-chain suitability support reliable machine automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC699 provides a compact and reliable connection solution for industrial sensors and automation components. Its 1.5 m length is suitable for short-distance machine wiring.
The cable uses straight M8 connectors with A-coding and gold-plated contacts. The 3 × 0.25 mm² PUR cable provides reliable signal transmission and flexible routing.
The cable is designed with halogen-free and silicone-free materials. Robust connector construction and FKM sealing help support reliable operation in industrial environments.
The EVC699 is suitable for industrial automation, machine tools and moving equipment. Its IP65, IP67, IP68 and IP69K protection supports use in demanding conditions.
1.5 m cable length
Straight M8 connectors
M8 plug-to-socket connection
A-coded design
3 × 0.25 mm² PUR cable
3.7 mm cable diameter
Gold-plated contacts
Halogen-free
Silicone-free
TPU connector body
FKM sealing
Nickel-plated brass locking
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
Oil and coolant resistant
Industrial automation
Factory automation
Sensor connections
Machine tools
Production machinery
Machine control systems
Automation equipment
Moving machinery
Cable-chain applications
Industrial control systems
| Specification | Details |
|---|---|
| Product Code | EVC699 |
| Model | VDOGF040MSS01,5H03STGF030MSS |
| Product Type | Connection Cable |
| Cable Length | 1.5 m |
| Connector Type | M8 |
| Connector Design | Straight |
| Coding | A-coded |
| Number of Contacts | 3 |
| Cable Material | PUR |
| Cable Cross Section | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Contact Material | Gold-plated |
| Housing Material | TPU |
| Nut Material | Nickel-plated Brass |
| Sealing Material | FKM |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25 to +90 °C |
| Drag Chain Suitable | Yes |
| Bending Cycles | > 5 million |
| Maximum Travel Speed | 3.3 m/s |
