The IFM EVC678 is a compact 0.3 m connection cable designed for industrial automation connections. It features an angled M12 plug and an M8 socket, providing a flexible interface between different connector sizes. The 4-conductor PUR cable provides reliable signal transmission and mechanical durability. High IP protection and drag-chain suitability support demanding machine applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Introduction
The EVC678 provides a compact connection solution for industrial sensors and automation components requiring M12 and M8 interfaces. Its short cable length is suitable for space-restricted machine installations.
Connector Configuration
The cable combines an angled M12 plug with an M8 socket. The A-coded configuration and gold-plated contacts provide reliable electrical connectivity.
Durable Cable Construction
The PUR cable and robust TPU connector housings are designed for industrial environments. FKM sealing and nickel-plated brass locking components provide additional environmental protection.
Application Performance
The cable is suitable for automated machinery, sensors and actuators. Its high IP protection, oil and coolant resistance and drag-chain suitability support dependable operation in demanding environments.
Key Features
0.3 m cable length
M12 angled plug
M8 straight socket
M12 to M8 connection
4-pin configuration
A-coded design
4 × 0.34 mm² PUR cable
Gold-plated contacts
Halogen-free
Silicone-free
Oil and coolant resistant
FKM sealing
IP65, IP67, IP68 and IP69K protection
Drag-chain suitable
More than 5 million bending cycles
Applications
Industrial automation
Factory automation
M12 to M8 sensor connections
Machine control systems
Sensor and actuator connections
Production machinery
Moving machinery
Compact machine installations
Industrial control equipment
| Specification | Details |
|---|---|
| Product Code | EVC678 |
| Model | VDOGH046MSS00,3H04STAF040MSS |
| Product Type | Connection cable |
| Cable Length | 0.3 m |
| Connector 1 | M12 angled plug |
| Connector 2 | M8 straight socket |
| Connection | M12 to M8 |
| Coding | A-coded |
| Number of Contacts | 4 |
| Cable Material | PUR |
| Cable Cross Section | 4 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Operating Voltage | 10–36 V DC |
| Maximum Current | 4 A |
| Protection Class | II |
| Protection Rating | IP65, IP67, IP68, IP69K |
| Ambient Temperature | -25 to +90 °C |
| Minimum Bending Radius | 10 × cable diameter |
| Maximum Travel Speed | 3.3 m/s |
| Bending Cycles | > 5 million |
| Torsional Strain | ±180°/m |
| Sealing Material | FKM |
| Contacts | Gold-plated |
| Cable Chain Suitable | Yes |
