The IFM EVC674 is a compact 0.3 m connection cable designed for reliable connections between M8 and M12 components in industrial automation systems. It features an angled M8 plug and a straight M12 socket with A-coded, gold-plated contacts. The PUR cable provides excellent durability and flexibility for demanding industrial environments. Its PNP design, high IP protection and drag-chain suitability make it suitable for machine and factory automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Introduction
The EVC674 connection cable provides a reliable interface between compatible industrial sensors, actuators and automation components. Its compact 0.3 m design is suitable for installations where space is limited while maintaining a secure electrical connection.
Connector and Cable Design
The cable features an angled M8 plug on one side and a straight M12 socket on the other. Both connectors use A-coded contacts, while the 3 × 0.34 mm² PUR cable provides flexible and reliable signal transmission. The contacts are gold-plated for dependable electrical performance.
Industrial Durability
The EVC674 is designed with halogen-free and silicone-free materials. The connector housings are made from TPU, with nickel-plated brass nuts and FKM sealing. The cable is resistant to oils and coolants and is suitable for demanding industrial environments.
Application Performance
The cable supports 10–36 V DC operation and a maximum total load current of 3 A. It provides IP65, IP67, IP68 and IP69K protection and can be used in cable chains. For dynamic applications, it supports a minimum bending radius of 10 times the cable diameter, travel speeds up to 3.3 m/s and more than 5 million bending cycles.
Key Features
0.3 m compact connection cable
M8 angled plug
M12 straight socket
M8 to M12 connection
A-coded connectors
3 × 0.34 mm² PUR cable
Gold-plated contacts
PNP electrical design
10–36 V DC operating voltage
Maximum total load current of 3 A
Halogen-free construction
Silicone-free design
Oil and coolant resistant
FKM sealing
IP65, IP67, IP68 and IP69K protection
Suitable for cable-chain applications
More than 5 million bending cycles
Integrated LED status indication
Applications
Industrial automation systems
Factory automation equipment
Sensor and actuator connections
Machine control systems
Industrial machinery
Production equipment
M8 to M12 sensor connections
Compact machine installations
Moving machinery
Cable-chain applications
Industrial control systems
Automation equipment requiring PNP connections
| Specification | Details |
|---|---|
| Product Code | EVC674 |
| Manufacturer | IFM |
| Product Type | Connection Cable |
| Model | VDOGH034MSS00,3H03STAF030MSS |
| Cable Length | 0.3 m |
| Connector 1 | M8 Angled Plug |
| Connector 2 | M12 Straight Socket |
| Connection Type | M8 to M12 |
| Coding | A-coded |
| Electrical Design | PNP |
| Operating Voltage | 10–36 V DC |
| Maximum Current | 3 A |
| Cable Material | PUR |
| Cable Cross Section | 3 × 0.34 mm² |
| Cable Diameter | 4.3 mm |
| Protection Rating | IP65, IP67, IP68, IP69K |
| Protection Class | III |
| Ambient Temperature | -25 °C to +90 °C |
| Minimum Bending Radius | 10 × Cable Diameter |
| Maximum Travel Speed | 3.3 m/s |
| Bending Cycles | > 5 million |
| Torsional Strain | ±180°/m |
| Connector Housing | TPU |
| Plug Housing Colour | Orange |
| Socket Housing | Black transparent |
| Nut Material | Nickel-plated Brass |
| Sealing Material | FKM |
| Contacts | Gold-plated |
| Plug Tightening Torque | 0.3–0.5 Nm |
| Socket Tightening Torque | 0.6–1.5 Nm |
| Status Indication | 2 × Yellow LED |
| Operating Indication | 2 × Green LED |
| Cable-Chain Suitable | Yes |
| Halogen-Free | Yes |
| Silicone-Free | Yes |
| Oil Resistant | Yes |
| Coolant Resistant | Yes |
| Weight | 37.8 g |
