The IFM EVC674 is a compact 0.3 m connection cable designed to connect M8 and M12 industrial automation components. It features an angled M8 plug and straight M12 socket for flexible installation in compact machine layouts. The PUR cable provides reliable performance, while gold-plated contacts and FKM sealing support dependable connections. High IP protection makes it suitable for demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Introduction
The EVC674 provides a compact interface between M8 and M12 components in industrial automation systems. Its short cable length is useful where space is limited and direct connection between different connector sizes is required.
Connector Configuration
The cable features an angled M8 plug and straight M12 socket. Both connectors use A-coded contacts, while gold-plated contacts support dependable electrical signal transmission.
Compact and Durable Design
The 0.3 m PUR cable has a 3 × 0.34 mm² construction. TPU connector bodies, FKM sealing and nickel-plated brass locking components provide reliable protection against industrial operating conditions.
Application Performance
The EVC674 supports 10–36 V DC operation and up to 3 A current. It provides IP65, IP67, IP68 and IP69K protection and is suitable for drag-chain applications with more than 5 million bending cycles.
Key Features
0.3 m compact cable
M8 angled plug
M12 straight socket
M8 to M12 connection
A-coded connectors
3 × 0.34 mm² PUR cable
Gold-plated contacts
Halogen-free construction
Silicone-free design
FKM sealing
IP65, IP67, IP68 and IP69K protection
Drag-chain suitable
Applications
Industrial automation
Factory automation
M8 to M12 sensor connections
Machine control systems
Compact machinery
Sensor and actuator connections
Production equipment
Moving machine applications
| Specification | Details |
|---|---|
| Product Code | EVC674 |
| Model | VDOGH034MSS00,3H03STAF030MSS |
| Product Type | Connection cable |
| Cable Length | 0.3 m |
| Connector 1 | M8 angled plug |
| Connector 2 | M12 straight socket |
| Coding | A-coded |
| Cable Material | PUR |
| Cable Cross Section | 3 × 0.34 mm² |
| Cable Diameter | 4.3 mm |
| Operating Voltage | 10–36 V DC |
| Current Rating | 3 A |
| Electrical Design | PNP |
| Protection Class | III |
| Protection Rating | IP65, IP67, IP68, IP69K |
| Ambient Temperature | -25 to +90 °C |
| Minimum Bending Radius | 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | > 5 million |
| Torsional Strain | ±180°/m |
| Contacts | Gold-plated |
| Sealing | FKM |
