The IFM EVC673 is a 3 m connection cable designed for reliable M8-to-M8 connections in industrial automation systems. It features straight M8 connectors, a flexible PUR cable and gold-plated contacts. The cable is resistant to oils and coolants and provides high protection against harsh environmental conditions. Its drag-chain suitability supports reliable operation in moving machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Introduction
The EVC673 provides a dependable connection between industrial sensors and automation components using M8 interfaces. Its compact connector design is suitable for sensor and actuator installations.
Connector and Cable Design
The cable features straight M8 connectors with A-coded connections. The 3 m PUR cable uses a 3 × 0.25 mm² construction and gold-plated contacts for reliable electrical signal transmission.
Durable Industrial Construction
TPU connector housings, FKM sealing and nickel-plated brass locking nuts provide reliable mechanical protection. The cable is halogen-free and silicone-free for demanding industrial installations.
Application Performance
The EVC673 provides IP65, IP67, IP68 and IP69K protection. It supports drag-chain applications with a minimum bending radius of 10 times the cable diameter, travel speeds up to 3.3 m/s and more than 5 million bending cycles.
Key Features
3 m PUR cable
M8 straight connector on both ends
M8 to M8 connection
A-coded design
3 × 0.25 mm² cable
Gold-plated contacts
Halogen-free construction
Silicone-free design
Oil and coolant resistant
FKM sealing
IP65, IP67, IP68 and IP69K protection
Drag-chain suitable
Applications
Industrial automation
Factory automation
M8 sensor connections
Machine control systems
Production machinery
Sensor and actuator connections
Moving machinery
Drag-chain installations
| Specification | Details |
|---|---|
| Product Code | EVC673 |
| Model | VDOGF040MSS0003H03STGF040MSS |
| Product Type | Connection cable |
| Cable Length | 3 m |
| Connector 1 | M8 straight |
| Connector 2 | M8 straight |
| Coding | A-coded |
| Cable Material | PUR |
| Cable Cross Section | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Operating Voltage | < 50 V AC / < 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65, IP67, IP68, IP69K |
| Ambient Temperature | -25 to +90 °C |
| Minimum Bending Radius | 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | > 5 million |
| Torsional Strain | ±180°/m |
| Contacts | Gold-plated |
