The IFM EVC651 is a 15 m shielded connecting cable with an angled M12 socket for industrial automation applications. It features a 4-conductor PUR cable with gold-plated contacts and robust FKM sealing. The cable is designed for demanding machine environments and is suitable for drag-chain applications. Its long cable length supports flexible installation where extended sensor connections are required.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Introduction
The EVC651 is designed to provide dependable electrical connections for sensors and automation equipment using M12 interfaces. Its 15 m length provides flexibility for larger machines and production systems.
Angled Connector Design
The product features an angled M12 socket with four contacts and A-coded configuration. The angled design can help simplify cable routing where installation space is restricted.
Shielded and Durable Cable
The EVC651 uses a shielded 4 × 0.34 mm² PUR cable with a 4.9 mm diameter. The cable is halogen-free, while gold-plated contacts and FKM sealing provide reliable industrial performance.
Application Performance
The cable operates below 50 V AC / 60 V DC, supports 4 A current and provides IP65, IP67, IP68 and IP69K protection. It is suitable for drag-chain use with more than 2 million bending cycles.
Key Features
15 m cable length
M12 angled socket
4-pin connection
A-coded design
Shielded PUR cable
4 × 0.34 mm² cable
Gold-plated contacts
Halogen-free construction
Silicone-free design
FKM sealing
IP65, IP67, IP68 and IP69K protection
Drag-chain suitable
Applications
Industrial automation
Factory automation
Machine tools
Sensor connections
Control systems
Production machinery
Moving machine applications
Long-distance sensor wiring
| Specification | Details |
|---|---|
| Product Code | EVC651 |
| Model | ADOAH040MSS0015C04 |
| Product Type | Connecting cable with socket |
| Cable Length | 15 m |
| Connector | M12 angled socket |
| Number of Contacts | 4 |
| Coding | A-coded |
| Cable Material | PUR |
| Cable Cross Section | 4 × 0.34 mm² |
| Cable Diameter | 4.9 mm |
| Cable Type | Shielded |
| Operating Voltage | < 50 V AC / < 60 V DC |
| Current Rating | 4 A |
| Protection Class | III |
| Protection Rating | IP65, IP67, IP68, IP69K |
| Ambient Temperature | -25 to +90 °C |
| Minimum Bending Radius | 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | ≥ 2 million |
| Torsional Strain | ±180°/m |
| Contacts | Gold-plated |
