IFM EVC478 is a 4.5 m M8 connection cable designed for reliable industrial automation applications. It features straight M8 plug and socket connectors with gold-plated contacts. The PUR cable provides flexibility, durability and resistance to demanding operating conditions. It is suitable for sensors, actuators and machine automation systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Reliable M8 Connectivity
EVC478 provides a dependable electrical connection between compatible industrial automation components. Straight M8 connectors support simple installation and secure locking. Gold-plated contacts help maintain reliable signal transmission. It is suitable for sensor and actuator applications.
4.5 m Cable Reach
The 4.5 m cable provides useful reach across industrial machines and production equipment. PUR construction allows flexible routing around machine components. The cable is resistant to mechanical wear. Its black sheath provides a practical industrial finish.
Durable Industrial Design
The cable is designed for vibration and shock resistance. Brass, nickel-plated locking components help provide secure connections. Its construction supports repeated movement in suitable applications. Drag-chain suitability provides additional flexibility.
High Environmental Protection
EVC478 provides high protection against dust, water and industrial contaminants. The cable is resistant to oils and coolants. Silicone-free and halogen-free construction supports demanding industrial applications. It is suitable for factory automation and machine-tool environments.
4.5 m PUR cable
M8 plug and M8 socket
Straight / straight design
3 × 0.25 mm² conductors
Gold-plated contacts
50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Oil and coolant resistant
Halogen-free
Silicone-free
Drag-chain suitable
High bending-cycle capability
Industrial automation
Factory automation
Machine tools
Sensor connections
Actuator wiring
Robotic machinery
Production equipment
Industrial control systems
| Specification | Details |
|---|---|
| Product Code | EVC478 |
| Product Type | Connection Cable |
| Manufacturer | IFM |
| Order Code | VDOGF030MSS0045H03STGF030MSS |
| Cable Length | 4.5 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | Approx. 3.7 mm |
| Conductors | 3 × 0.25 mm² |
| Connector A | M8 plug |
| Connector B | M8 socket |
| Connector Design | Straight / Straight |
| Coding | A |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Contacts | Gold-plated |
| Housing | TPU |
| Nut | Brass, nickel-plated |
| Sealing | FKM |
| Ambient Temperature | -25 to 90 °C |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
