IFM EVC470 is a 10 m connecting cable with a straight M8 plug designed for industrial automation systems. It provides extended cable reach for sensors and automation components installed farther apart. The PUR cable offers flexibility and mechanical durability. High environmental protection supports reliable operation in industrial conditions.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Extended Connection Range
EVC470 provides a 10 m cable length for installations requiring additional reach. The cable helps connect sensors and automation components across larger machine assemblies. Its straight M8 connector supports easy installation. The secure locking mechanism helps prevent accidental disconnection.
Durable Cable Construction
The PUR cable provides flexibility and resistance to mechanical wear. Its 4 × 0.25 mm² conductor construction supports reliable signal and power connections. The black sheath is suitable for industrial installations. It can be routed around machine components.
Reliable Electrical Performance
The cable supports up to 50 V AC and 60 V DC with a 3 A current rating. Gold-plated contacts provide reliable electrical conductivity. The M8 connector is designed for stable industrial connections. This makes the cable suitable for sensors and control equipment.
Industrial Protection
EVC470 provides IP65, IP67, IP68 and IP69K protection. It is suitable for environments exposed to dust, water, oils and coolants. The cable is free from silicone and halogens. Drag-chain suitability supports applications involving cable movement.
10 m PUR cable
Straight M8 plug
4 × 0.25 mm² conductors
Gold-plated contacts
50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Oil and coolant resistant
Halogen-free
Silicone-free
Drag-chain suitable
Vibration and shock resistant
Industrial automation
Factory automation
Machine tools
Sensor wiring
Actuator connections
Production machinery
Robotic systems
Industrial control equipment
| Specification | Details |
|---|---|
| Product Code | EVC470 |
| Product Type | Connecting Cable with Plug |
| Manufacturer | IFM |
| Order Code | ASTGF040MSS0010H04 |
| Cable Length | 10 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | 3.7 mm |
| Conductors | 4 × 0.25 mm² |
| Connector | 1 × M8 plug |
| Connector Design | Straight |
| Coding | A |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Contacts | Gold-plated |
| Housing | TPU, orange |
| Locking Nut | Brass, nickel-plated |
| Ambient Temperature | -25 to 90 °C |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
