IFM EVC448 is a compact 0.5 m M8 connection cable designed for reliable connections between industrial automation components. It features an angled M8 plug and straight M8 socket with gold-plated contacts. The PUR cable provides flexible, durable and protected connectivity for sensors, actuators and automation equipment.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Reliable M8 Connectivity
EVC448 provides dependable electrical connectivity between compatible automation components. Its M8 plug and socket configuration supports convenient integration into industrial systems. Gold-plated contacts help maintain reliable signal transmission. The cable is suitable for factory automation and machine applications.
Compact Cable Design
The 0.5 m cable length is suitable for short-distance machine connections. PUR construction provides flexibility and mechanical strength for industrial use. Its compact design helps maintain organized cable routing. It is useful where equipment is positioned close together.
Durable Industrial Construction
The cable is designed to withstand demanding industrial conditions. Its halogen-free and silicone-free construction supports safe and reliable machine installation. The connector housing is designed for mechanical durability. It is suitable for applications exposed to oils and coolants.
High Environmental Protection
EVC448 provides IP65, IP67, IP68 and IP69K protection. This helps protect the connection against dust, water and other environmental conditions. The locking mechanism supports resistance to vibration and shock. It is suitable for demanding industrial environments.
0.5 m PUR cable
M8 plug and M8 socket
Angled / straight connector design
3 × 0.25 mm² conductor construction
Gold-plated contacts
50 V AC / 60 V DC operation
AC/DC electrical design
Halogen-free cable
Silicone-free construction
IP65 / IP67 / IP68 / IP69K protection
Oil and coolant resistant
Drag-chain suitable
Industrial automation systems
Factory automation equipment
Sensor connections
Actuator connections
Machine tools
Robotic machinery
Control panels and machine wiring
Automated production equipment
| Specification | Details |
|---|---|
| Product Code | EVC448 |
| Product Type | Connection Cable |
| Manufacturer | IFM |
| Order Code | VDOAF030MSS00,5H03STGF030MSS |
| Cable Length | 0.5 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | Approx. 3.7 mm |
| Conductor | 3 × 0.25 mm² |
| Connection Type | M8 plug / M8 socket |
| Connector Design | Straight / Angled |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Contacts | Gold-plated |
| Housing Material | TPU |
| Nut Material | Brass, nickel-plated |
| Sealing | Viton |
| Ambient Temperature | -25 to 90 °C |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
